34 DSR Switch Installer/User Guide
To set virtual media options:
1. If the OSCAR interface is not open, press Print Screen to open the Main dialog box.
2. Click Setup - VM to open the Virtual Media dialog box shown in Figure 3.15.
Figure 3.15: OSCAR Interface Virtual Media Dialog Box
3. Click to enable or disable each of the options. For information about individual settings, see
Table 3.6.
4. Click OK to accept the options you have selected and return to the Setup dialog box.
Managing server tasks using the OSCAR interface
From the OSCAR interface Commands dialog box, you can manage your DSR switching system
and user connections, enable the Scan and Broadcast modes and update your firmware.
Mass Storage Allows virtual media sessions to the first detected mass storage drive. Enable this
checkbox to establish a virtual media mass storage connection to a server. Disable to end
a virtual media mass storage connection to a server.
Write Access Allows a target server to write data to the virtual media during a virtual media session.
Read access is always allowed during a virtual media session.
Table 3.6: Virtual Media Options (Continued)
Function Purpose
