Azbil MagneW FLEX+ User Manual

Introduction Azbil Corporation
1-2 MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector
1.2 : System operation
Introduction
Depending on how it is combined with the converter, this product is available in two
congurations, integral and remote.
• Integral: Detector and converter are installed as an integrated unit on a pipe.
• Remote: Detector and converter are installed connected by cable.
1.2.1: Integral type
Figure 1-2 and Figure 1-3 show examples of measurement systems using the device.


/





Figure 1-2 Integral conguration
