Azbil MagneW FLEX+ User Manual

Azbil Corporation Installation
MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector 2-25
2.5 : Installing a anged detector
CAUTION
Before installing the detector, make sure any foreign matter is ushed from
the interior passage of the detector. Residual foreign matter could cause output
uctuations.
Do not touch the electrodes or allow oil or fat to come into contact with them to
avoid output uctuations.
Align the direction mark on the detector in the direction of the liquid ow.
Misalignment can result in a negative output.
The following gure shows the basic installation method for installing a anged
detector.
Nuts (optional)
Through-bolts (optional)
Pipe
Gasket (Required when
using SUS material
grounding rings.
Otherwise, a gasket is
supplied.)
Figure 2-21 Installing a anged detector
