To install a wafer detector on a PVC pipe using SUS grounding ring material
and a protective plate:
Use this method to install the detector using a protective plate to prevent the PVC
pipe from being deformed or damaged when the bolts are tightened with the specied
torque.
• Install the protective plate between the outer side of the PVC ange and the
detector, as shown in the gure below. The protective plate protects the PVC
pipe. The torque level for tightening the bolts is not related to the gasket material.
See Table 2-1 on page 2-7 for the appropriate torque.
See Table 2-2 on page 2-10 for the inner diameter of the gasket.
Lining
Gasket
Grounding ring
Protective plate
Figure 2-16 Installation on a PVC pipe using SUS grounding ring material and a
protective plate
