Azbil MagneW FLEX+ User Manual

Installation Azbil Corporation
2-14 MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector
2.4.6: Installation on a vertical pipe
Follow this procedure to install the detector on a horizontal pipe.
Step Action Drawing
1 • Of the ange holes shown by black dots in the
drawing, insert through-bolts into the two holes
at the back and fasten them lightly with nuts.
Slip one centering nut onto each through bolt
before inserting the bolts.
Flange
Terminal
box side
Back
Centering nuts
2 • Turn the detector so that the direction mark on
the detector matches the direction of uid ow.
• Insert the detector and gaskets between the pipe
anges.
Gaskets
Direction of
fluid flow
3 • Insert through-bolts tted with one centering
nut each into the remaining two ange holes
shown by black dots in steps 1 and 2.
Gaskets
Direction of
fluid flow
4 • Make sure that the detector remains properly
centered.
• Make sure that the gaskets do not protrude
beyond the edges of the pipe anges.
• When you have checked these items, insert
the remaining through-bolts into the ange
holes and tighten the bolts evenly using the
appropriate fastening torque given on page
2-7.
