Azbil MagneW FLEX+ User Manual

Azbil Corporation Introduction
MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector 1-7
1.3.3: Union / Hose / Clamp type detector
Grounding terminal
Waterproof
gland
Flow direction
mark
Electrode
cover
Hose
Clamp
Union
Mounting screw(4 places)
Terminal box
Terminal box cover
Figure 1-6 Union / Hose / Clamp detector main parts
Name Function
Flow direction mark Indicates the direction of uid ow.
Mount the detector so that the measured uid ows in the
direction indicated by this mark.
Electrodes The electrodes generate an electromotive force signal
proportional to the ow rate of the uid passing through
the detector. The electrode material varies depending on
the corrosion characteristics of the uid to be measured.
Electrode cover Houses the electrodes. Do not remove the cover with the
detector installed on a pipe.
Union (Connected by
screws)
Hose
Clamp
The connection uses a union, hose, and clamp. The
material is SUS316.
Applicable for detector bore diameters of 2.5 to 15 mm.
Terminal box
(Remote model only)
Houses the connection terminals used to apply a standard
voltage.
Houses excitation and signal terminals.
Terminal box cover
(Remote model only)
Keeps the terminals box cover on during operation.
