2-32 MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector
Table 2-7 Recommended inner diameters of gaskets
Bore diameter mm (inch) Inner diameter mm (inch)
1100 (44) 1101±2 (43.35±0.08)
2.5.3: Selecting an installation method
To select an installation method you must determine the following:
• Mounting pipe material (metal or PVC)
• Grounding ring material (SUS or non-SUS)
• Need for a protective plate
• Use of rubber gaskets
CAUTION
The necessary materials and the installation method vary according to the material
of the ring and that of the pipe on which the detector is to be installed. Select the
appropriate method of installation from the following table after conrming the
specications of the detector to be installed and the conditions of installation.
Improper installation can result in leakage or damage to the pipe anges.
Table 2-8 Flange detector installation methods
Pipe
material
Grounding ring
material
Installation requirements See Page
Metal SUS material With specied fastening torque page 2-33
Non-SUS material With specied fastening torque page 2-34
PVC SUS material With specied fastening torque page 2-36
With a protective plate page 2-37
With rubber gaskets and low
fastening torque
page 2-38
Non-SUS material With specied fastening torque page 2-40
With a protective plate page 2-41
With rubber gaskets and low
fastening torque
page 2-42
