Introduction Azbil Corporation
1-6 MagneW FLEX+/PLUS+ Electromagnetic Flowmeter Detector
1.3.2: Flange type detector
A Flange detector consists of the components shown in the gure below.
Mounting screw
(4 places)
Electrode cover
Waterproof gland
Grounding terminal
Terminal box cover
Terminal box
Flow direction mark
Flange
Grounding ring
Figure 1-5 Flange detector main parts
Name Function
Flow direction mark Indicates the direction of uid ow. Mount the detector
so that the measured uid ows in the direction indicated
by this mark.
Electrodes Detect an electromagnetic force signal proportional to
the ow rate of the uid passing through the detector.
The electrode material varies depending on the corrosion
characteristics of the uid to be measured.
Electrode cover Houses the electrodes. Do not remove the cover with the
detector installed on a pipe.
Grounding rings Keep reference voltage as zero by grounding the unit.
The grounding ring material varies depending on the
corrosion characteristics of the uid to be measured.
Terminal box
(Remote model only)
Houses the connection terminals used for applying
a standard voltage. Houses the excitation and signal
terminals.
Terminal box cover
(Remote model only)
Keeps the terminals dry and protected. Keeps the
terminal box cover on during operation.
