R5905752 /16 DP2K C24
UPS requirements
The Uninterruptible Power Supply (UPS), also known as a Continuous Power Supply (CPS), must have an
output voltage of 200-240V at 50-60Hz and must be capable of delivering an output current of 5,5 amperes.
The connection between the UPS unit and the UPS inlet of the projector must be done with a certified AC
power supply cord of minimum 0,75 mm² or 18 AWG and minimum 300V.
CAUTION: The 200–240V power outlet (UPS OUTLET) of the projector may not be used to provide
the UPS unit with power! The UPS OUTLET of the projector may only be used for connection to the
UPS INLET of the projector.
The DP2K-xxC does not have a built in UPS unit.
Projector weight
Do not underestimate the weight of the Barco DP2K-xxC.
The projector weights are without lens. Be sure that the pedestal on which the projector has to be installed is
capable of handling the complete load of the system.
Projector Weight
DP2K-12C ±100 kg (±200 lb.)
DP2K-15C ±102 kg (±225 lb.)
DP2K-20C ±102 kg (±225 lb.)
DP2K-12Cx ±100 kg (±200 lb.)
DP2K-15Cx ±102 kg (±225 lb.)
DP2K-20Cx ±102 kg (±225 lb.)
Barco offers a pedestal for the DP2K-xxC. This universal pedestal allows a solid and easy setup of
the projector. The universal pedestal has a separate compartment to install the UPS unit for the
DP2K-xxC. Futhermore, the universal pedestal contains a standard 19” rack to build in the projector
peripherals such as alternative content switchers.
2.2 Unpacking the projector
What has to be done ?
At delivery the projector is packed in a carton box upon a wooden pallet and secured with banding and
fastening clips. Furthermore, to provide protection during transportation, the projector is surrounded with
foam. Once the projector has arrived at the installation site, it has to be removed from the carton box and
wooden pallet in a safe manner without damaging the projector.
After unpacking let the projector acclimate to the room temperature which must be higher then 10°C
(50°F) and lower then 35°C (95°F). Neglecting this may result in a start up failure of the Light
Processor Unit.
Required tools
• Allen wrench 8 mm
• Open end wrench 13 mm
• Open end wrench 17 mm
How to unpack the projector ?
1. Remove the banding around the carton box, by releasing the fastening clips as illustrated, and open the
box.
