R5905752 /16 DP2K C94
Situation Solution
3. Switch on the power.
Result: As soon the new HDD is detected by the
ICMP-X the rebuild of the RAID is started (Blinking
red LED).
Multiple disks failed (multiple red LEDs) + Error
10573 “The RAID is broken”.
Note: The disk status (RAID broken) can be
retrieved via the (Web) Commander. See user guide
of the (Web) Commander.
1. Switch off the power.
2. Replace all defect HDDs with approved models of
the same storage capacity. See procedure
“Removing a HDD from the ICMP-X”, page 92,
and “Installing a HDD into the ICMP-X”, page 90.
Ensure to insert the HDDs firmly.
3. Switch on the power.
4. Start “RAID Initialize”. See user guide of the
(Web) Communicator.
Result: a new empty RAID is created.
A set of HDDs initialized for a GEN 2 storage
controller is installed on a GEN 1 storage controller
(All red LEDs remain off) + Combination of three
errors (10580 “local storage not available”, 10585
“storage mount failed”, 10573 “the RAID is
broken”)
Note: The disk status (Error code) can be retrieved
via the (Web) Commander. See user guide of the
(Web) Commander.
1. To avoid any misidentification, double check
ICMP model and if HDD model is compatible with
installed storage controller (see list of HDD
models validated by Barco).
2. Start “RAID Initialize”. See user guide of the
(Web) Communicator. Note that all content will be
lost!
Result: a new empty RAID is created.
All HDD LEDs remain off + Error 10580 “local
storage not available”.
Note: The disk status (Error code) can be retrieved
via the (Web) Commander. See user guide of the
(Web) Commander.
1. Switch off the power.
2. Reseat all HDDs. See procedure “Removing a
HDD from the ICMP-X”, page 92, and “Installing a
HDD into the ICMP-X”, page 90. Ensure to insert
the HDDs firmly.
3. If problem remains try “RAID Initialize”. See user
guide of the (Web) Communicator. Note that all
content will be lost!
4. If problem remains contact Service for further
instructions.
In case the ICMP-X has to be returned to factory (e.g. for repair) the non defective HDDs should be
removed and kept.
7.7 ICMP-X status LEDs
ICMP-X status LEDs and Reset button
LEDs on ICMP-X front panel give information on the status of the device.
ICMP-X
