R5905752 /16 DP2K C42
3. Release the three spring lock screws of the lamp house as illustrated.
Image 4–4 Release lamp house
4. Take the lamp house by the handles and pull it out of the projector.
Caution: Be aware of the weight of the lamp assembly. Take the necessary precautions to avoid
personal injury.
Image 4–5 Remove lamp house
5. Place the lamp house on a stable support.
While starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is
not possible to start up the projector.
4.3 Removal of the xenon lamp
WARNING: DO NOT PERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY
PHASE OF XENON LAMP HANDLING OR SERVICE. ONLY TRAINED AND QUALIFIED
TECHNICAL SERVICE PERSONNEL ARE ALLOWED TO HANDLE THE XENON LAMP.
WARNING: This procedure may only be performed by qualified technical service personnel.
