SB-170-1044
For work on the compressor once it has been
commissioned
WARNING
The compressor is under pressure!
Serious injuries are possible.
Depressurize the compressor!
Wear safety goggles!
CAUTION
Surface temperatures of more than 60°C or be-
low0°C.
Risk of burns or frostbite.
Close off accessible areas and mark them.
Before performing any work on the compressor:
switch it off and let it cool down or warm up.
For work on the electrical and/or electronic system
WARNING
Risk of electric shock!
Before working on the terminal box, module
housing and electrical lines: Switch off the main
switch and secure it against being switched on
again!
Close the terminal box and the module housing
before switching on again!
!
!
NOTICE
The compressor module may be damaged or
fail!
Never apply any voltage to the terminals of CN7
to CN12 – not even for test purposes!
The voltage applied to the terminals of CN13
must not exceed 10V!
The voltage applied to terminal 3 of CN14 must
not exceed 24V! Do no apply voltage to the
other terminals!
3 Application ranges
Compressor types Permitted refrigerants Oil types Application limits
CSH65 .. CSH95 R134a, R407C, R450A, R513A,
R1234yf, R1234ze(E)
BSE170 See brochure SP-171 and
BITZER SOFTWARE
CSH65 .. CSH95 R22 B320SH See brochure SP-171 and
BITZER SOFTWARE
CSH105 R134a, R450A, R513A, R1234yf,
R1234ze(E)
BSE170 See BITZER SOFTWARE
CSH76 .. CSH96 R134a, R450A, R513A, R1234yf,
R1234ze(E)
BSE170L See BITZER SOFTWARE
CSK61 .. CSK71 R22 B320SH See BITZER SOFTWARE
CSW65 .. CSW95 R134a, R407C, R450A, R513A,
R1234yf, R1234ze(E)
BSE170L See brochure SP-172 and
BITZER SOFTWARE
CSW65 .. CSW95 R22 B320SH See brochure SP-172 and
BITZER SOFTWARE
CSW85 .. CSW105
(motor 4)
R134a, R450A, R513A, R1234yf,
R1234ze(E)
BSE55 See BITZER SOFTWARE
CSW105 R134a, R450A, R513A, R1234yf,
R1234ze(E)
BSE170L See BITZER SOFTWARE
Tab.1: Application ranges of CS. compressors
The use of R404A and R507A and other refrigerant
blends requires individual consultation with BITZER.
Application limits for CSK61 and CSK71
CSK61 and CSK71 compressors are only approved for
use with R22 refrigerant, without ECO and LI. The ap-
plication limits go down to -10°C. Above this value, the
application limits correspond to that for CSH65 resp.
CSH75 compressors with R22 refrigerant.
