Series CS.6.
• 1 protective earth conductor connection and 6 con-
nections for the motor power voltage supply, with a
cable terminal for conductor cross section of max.
35mm
2
each
▶ Mount wire end ferrules.
▶ Screw the cables into the cable terminals.
Series CS.7.
• 2 protective earth conductor connections and 6 con-
nections for the motor power voltage supply
– thread: M10x1,5
– Notch-type cable lugs for conductor cross section
of max. 35mm
2
are included in the scope of deliv-
ery.
– alternative cable lugs: maximum possible width
28mm, hole diameter between 10,5mm and
15mm
▶ Dismount the cable lugs.
▶ Mount the cable lugs at the cable ends.
▶ Remount the cable lugs and all dismounted compon-
ents in the same order .
Series CS.8. and models CS.9.53 to CS.9.93
• 2 protective earth conductor connections and 6 con-
nections for the motor power voltage supply
– thread: M10x1,5
– Select cable lugs according to the conductor
cross section demanded by the motor power.
maximum possible width of cable lug: 28mm,
hole diameter: 10,5mm
▶ Mount cable lugs at the cable ends.
▶ Mount the cable lugs as the lowermost part at each
protective earth conductor pin and motor pin.
▶ Remount the components in the same order.
Models CS.9.103 and CS.9.113
• 1 protective earth conductor connection and 6 con-
nections for the motor power voltage supply
– thread: M12x1,75
– Select cable lugs according to the conductor
cross section demanded by the motor power.
maximum possible width of cable lug: 28mm,
hole diameter at least 12,5mm
– Per pin up to two cable lugs may be mounted.
▶ Mount cable lugs at the cable ends.
▶ Mount the cable lugs as the lowermost part at each
protective earth conductor pin and motor pin.
▶ Remount the components in the same order.
Series CS.105
• 1 protective earth conductor connection and 6 con-
nections for the motor power voltage supply
– thread: M16x2
– Select cable lugs according to the conductor
cross section demanded by the motor power.
maximum possible width of cable lug: 60mm,
hole diameter at least 16,5mm
▶ Mount cable lugs at the cable ends.
▶ Mount the cable lugs as the lowermost part at each
protective earth conductor pin and motor pin.
▶ Remount the components in the same order.
6.5.3 Coating terminal plate and pins
In case of low temperature application with low suction
gas superheat, frost may form on the motor side and
partly also on the terminal box. To prevent voltage
flashovers due to moisture, coating of terminal plate
and pins with isolation paste is recommended.
6.5.4 Terminal box heater
For critical applications at lower temperatures, and es-
pecially at high humidity, it can be advantageous to
heat the terminal box. The terminal box cover can be
retrofitted with a heater for this purpose.
▶ Series HS.64, HS.74, CS.6. and CS.7.: Mount new
terminal box cover with integrated heater.
▶ From series HS.85 and CS.8. on: Screw the terminal
box heater at the corners, inserting the screws into
the holes in the centre of the terminal box cover.
▶ Connect the heater electrically.
▶ Preferably switch the voltage supply on and off via
an auxiliary NO contact to the 1st part winding or to
the main contactor (Y/Δ).
▶ Use a suitable fuse.
Technical data
• Power consumption: 30W
• available for 230V or 115V
