BLUM MINIPRESS PRO User Manual

7 BA-102/2EN M54.XXXX
• Beforeretooling,cleaning,maintenanceorperforminganyworkondrillbits,turnthemainswitch(2.1) to pos.0 and disconnect the
assembly machine from the pneumatic connection.
• Onlyusesharp,cleandrillbits.Attachdrillbitssecurely.
• Particularcaremustbetakenwhenworkingonsectionsthatjutoutovertheworktop.Attachalargerworktableoruseextensions.
• Securetheworkpieceduringdrilling/insertion.Usetheassemblymachineclampsorifthesearenotsufficientfortheparticularjob,
use suitable clamping equipment.
• Wearappropriateworkclothing.
• Youshouldalwayscheckthatallsafetydevicesandmachinepartsarefunctioningproperlybeforeuse.Replacedamagedparts
with original Blum parts.
• Makesurethatnoothertoolsorobjectsareontheworktableasidefromyourworkpiecebeforeturningontheassemblymachine.
• Alwaysturnthemainswitch(2.1) to POS. 0
• Foryourownsafety,onlyusethoseaccessorieswhicharerecommendedorindicatedintheinstructionleafletortheBLUM
catalogue.
• Donotmakeanyalterationsormodificationstotheassemblymachine.
• Ifthereareanyquestionsand/orproblems,pleasecontacttheBLUMCustomerServiceDepartment.
• Wearearprotection
• Makesurethattheworkareaisilluminatedproperly
• Allnationalregulationsregardinglabourlaw,industrialsafetyaswellasalldisposalguidelinesmustbefollowed.
D - Safety information
D.5 - Noise emission
The work place noise level LpA determined according to DIN EN ISO 11202 with Supplement CEN -TC 142 is 85 dB(A). The sound
power level LWA determined according to EN ISO 3746 with Supplement CEN-TC 142 is 92 dB(A). The measurement uncertainty
constant K is 4 dB (A).
The following supplements from CEN - TC142 to maintain an accuracy class better than 3 dB were taken into account:
The ambient correction factor K3A is 4 dB. The difference between the extraneous noise level and the sound intensity level at each
measuring point is 6 dB. The machine-specific measuring conditions were as follows taking into account ISO 7960 sections 0 through
4:
Drill bits: 1 boss hinge drill bit d= 35 mm; t= 12 mm, n= 2890 U/min
2 dowel drill bits d= 8 mm; t= 12 mm, n= 5600 U/min,
Work piece: Chipboard 300 x 700 x 19.
Microphone position: Centred 1 m in front of the drill axle at a height of 1.5 m
Note:
The values specified here are emission values, which means that they are not necessarily safe workplace values at the same time.
Because there is no correlation between emission values and workplace values, they cannot be used to reliably determine whether
or not additional precautions are required. Factors that can influence the current workplace value include the duration of exposure,
the type of work space, other sources of noise, the number of machines and other nearby influences. Also, admissible workplace
levels may vary from country to country. The information provided here is designed to enable users to assess the hazards and risks
involved more accurately.
D.6 - Dust emission
If connected properly to a dust extraction system, dust emissions fall clearly below the technical standard value. The assembly
machine is equipped with a connecting piece for hoses with an inside diameter of 50 mm. This provides negative pressure of 1000 Pa
for the maximum required average air velocity of 20 m/sec. If there is no extraction system connector with a diameter of 50 mm, the
supplied adapter can be used.
• Theassemblymachinemustbeconnectedtoadustextractionsystem.(Theextractionsystemconnectionmustbeflexibleand
flame resistant).
• Regularlyremoveremainingdustandchipsusingavacuumcleaner.
D.4 - Safety information
