H60 Heated Humidifier User Manual V2.0
12 / 21
water chamber (dip the soft cloth in mild scrubbing solutions if necessary), then rinsed
thoroughly, and at last wiped with soft cloth.
Fig. 5-8
5.7 Reassembling the Humidifier
(1) Set up the air-intake assembly: First install the sealing elements to the air intake, as
shown in the figure below.
Air Intake
Sealing Element
Air-intake AssemblySealing Element
Fig. 5-9
(2) Then install the air-intake assembly back to the main body of the humidifier, as shown in
the figure below.
Fig. 5-10
(3) Return the water chamber to the main body of the humidifier, as shown in the figure
below.
To Next Page
