BMW F 800 GT User Manual

Diagnostic connector
Removing the diagnostic
connector
CAUTION
Incorrect procedure followed
when disconnecting the data
link connector for the On-
Board Diagnostics.
Motorcycle experiences malfunc-
tions
Only have the data link con-
nector disconnected by a spe-
cialist workshop or other autho-
rized persons during your next
BMW Service appointment.
Have the work performed by
appropriately trained staff.
Refer to the vehicle manufac-
turer specifications.
Remove seat ( 52).
Press locks 1 on both sides.
Remove the diagnostic con-
nector 2 from the bracket 3.
Counter-hold the bracket while
doing so.
The diagnosis and information
system interface can be con-
nected at the diagnostic con-
nector 2.
Secure the data link
connector
Disconnect the diagnosis and
information system interface.
Insert diagnostic connector 2
into the bracket 3. Counter-
hold the bracket while doing
so.
The locking mechanisms 1 en-
gage on both sides.
Install the seat ( 52).
9
120
z Maintenance

BMW F 800 GT Specifications

General

Displacement	798 cc
Max Power	90 hp (66 kW) @ 8, 000 rpm
Max Torque	86 Nm (63 lb-ft) @ 5, 800 rpm
Transmission	6-speed
Seat Height	800 mm (31.5 inches)
Curb Weight	213 kg (470 lbs)
Fuel System	Electronic fuel injection
ABS	Standard
Fuel Capacity	15 l
Front Suspension	Telescopic fork
Engine Type	Liquid-cooled, 4-stroke, in-line two-cylinder
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
