BMW F 800 GT User Manual

Threaded fasteners
Front wheel Value Valid
Brake caliper on fork leg
M10 x 1.25 x 35 - 10.9 22 lb/ft (30 Nm)
Pinch bolt on quick-release axle
M8 x 30 Tighten the screws 6 times, alternating
between one and the other each time
14 lb/ft (19 Nm)
Quick-release axle in telescopic
fork
M24 x 1.5 37 lb/ft (50 Nm)
Rear wheel Value Valid
Rear wheel on drive shaft
M10 x 1.25 x 40 tighten diagonally
44 lb/ft (60 Nm)
12
135
z Technical data

BMW F 800 GT Specifications

General

Displacement	798 cc
Max Power	90 hp (66 kW) @ 8, 000 rpm
Max Torque	86 Nm (63 lb-ft) @ 5, 800 rpm
Transmission	6-speed
Seat Height	800 mm (31.5 inches)
Curb Weight	213 kg (470 lbs)
Fuel System	Electronic fuel injection
ABS	Standard
Fuel Capacity	15 l
Front Suspension	Telescopic fork
Engine Type	Liquid-cooled, 4-stroke, in-line two-cylinder
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
