BMW K1300R User Manual

Engine oil, specified level
Between MIN and MAX
marks
If the oil level is below the MIN
mark:
Topping up engine oil ( 102).
If the oil level is above the MAX
mark:
Have the oil level corrected
by a specialist workshop,
preferably an authorised BMW
Motorrad dealer.
Topping up engine oil
Removing the seat ( 67).
Wipe the area around the filler
neck clean.
Remove cap of oil filler neck 1
by turning it counter-clockwise.
Damage to the engine
can result if it is operated
without enough oil, but the same
also applies if the oil level is too
high.
Always make sure that the oil
level is correct.
Top up the engine oil to the
specified level.
Checking engine oil level
( 101).
Install cap of oil filler neck 1
and turn it clockwise to close.
Installing the seat ( 68).
Brake system
Reliability
A fully functional brake system is
a basic requirement for the road
safety of your motorcycle.
Do not ride the motorcycle if you
have any doubts about the de-
pendability of the brake system.
Under these circumstances have
the brake system checked by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
Incorrect working practices
endanger the reliability of
the brakes.
Have all work on the brake sys-
tem performed by a specialist
8
102
z Maintenance

BMW K1300R Specifications

General

Displacement	1293 cc
Transmission	6-speed
Fuel Capacity	19 liters (5.0 US gal)
Seat Height	820 mm (32.3 in)
Bore x Stroke	80 mm x 64.3 mm
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft
Rear Brake	Single 265 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	217 kg (478 lb)
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	173 hp (129 kW) at 9, 250 rpm
Torque	140 Nm at 8, 250 rpm
Weight	243 kg
Front Suspension	Duolever
Rear Suspension	Paralever
Front Brake	Dual 320 mm discs, 4-piston calipers
