Tighten adjusting screws 1.
If the motorcycle is on the
centre stand and is raised
too far, the centre stand will lift
clear of the ground and the mo-
torcycle could topple to one side.
When raising the motorcycle,
make sure that the centre stand
remains on the ground.
Apply uniform pressure to push
the front-wheel stand down
and raise the motorcycle.
Rear-wheel stand
Installing rear-wheel
stand
Use basic stand with tool num-
ber (0 402 245) in combin-
ation with rear-axle adapter
(0 402 250).
Use screws 1 to set the rear-
wheel stand to the desired
height.
Remove retaining disc 2. To
do so, press release button 3.
Remove retaining disc 2. To
do so, press release button 3.
Make sure the ground is level
and firm and place the motor-
cycle on its side stand.
Push the rear wheel stand from
the left into the rear axle.
Push on retaining disc 2 from
the right, while holding the re-
lease button down.
Grip the rear grab handle of the
motorcycle with your left hand
and use your right to grip the
handle of the rear-wheel stand.
8
118
z Maintenance

BMW K1300R Specifications

General

Displacement	1293 cc
Transmission	6-speed
Fuel Capacity	19 liters (5.0 US gal)
Seat Height	820 mm (32.3 in)
Bore x Stroke	80 mm x 64.3 mm
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft
Rear Brake	Single 265 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	217 kg (478 lb)
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	173 hp (129 kW) at 9, 250 rpm
Torque	140 Nm at 8, 250 rpm
Weight	243 kg
Front Suspension	Duolever
Rear Suspension	Paralever
Front Brake	Dual 320 mm discs, 4-piston calipers
