An uneven surface requires
softer damping than a smooth
surface.
An increase in spring preload
requires firmer damping, a re-
duction in spring preload re-
quires softer damping.
Adjust the damping for
rear wheel
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Adjust the damping character-
istic, using the tool from the
on-board toolkit to turn adjust-
ing screw 1.
If you want a harder damping
characteristic, turn adjusting
screw 1 in the direction indic-
ated by the H arrow.
If you want a softer damping
characteristic, turn adjusting
screw 1 in the direction indic-
ated by the S arrow.
Basic setting of rear-sus-
pension damping charac-
teristic
without Electronic Suspen-
sion Adjustment (ESA II)
OE
Basic setting of rear-sus-
pension damping charac-
teristic
Turn the adjusting screw as
far as it will go in the dir-
ection indicated by the H
arrow and then turn it back
one and a half turns in the
direction indicated by the S
arrow. (Full load of fuel, with
rider 85 kg)
Electronic Suspension
Adjustment ESA
with Electronic Suspension Ad-
justment (ESA II)
OE
Settings
Electronic Suspension Adjust-
ment ESA provides a convenient
way of adapting the motorcycle
to the load it carries and the sur-
face over which you intend riding.
In order for this to happen, the
4
64
z Operation

BMW K1300R Specifications

General

Displacement	1293 cc
Transmission	6-speed
Fuel Capacity	19 liters (5.0 US gal)
Seat Height	820 mm (32.3 in)
Bore x Stroke	80 mm x 64.3 mm
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft
Rear Brake	Single 265 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	217 kg (478 lb)
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	173 hp (129 kW) at 9, 250 rpm
Torque	140 Nm at 8, 250 rpm
Weight	243 kg
Front Suspension	Duolever
Rear Suspension	Paralever
Front Brake	Dual 320 mm discs, 4-piston calipers
