BMW K1300R User Manual

Installing front wheel
Possible malfunctions when
ABS and ASC systems in-
tervene if non-standard wheels
are installed.
See the information on the effect
of wheel size on the ABS and
ASC systems at the start of this
chapter.
Threaded fasteners not
tightened to the specified
torque can work loose or their
threads can suffer damage.
Always have the security of the
fasteners checked by a specialist
workshop, preferably an author-
ised BMW Motorrad dealer.
The front wheel must be
installed right way round to
rotate in the correct direction.
Note the direction-of-rotation ar-
rows on the tyre or the wheel
rim.
Roll the front wheel into posi-
tion between the front forks.
Raise the front wheel, insert
quick-release axle 3 and tight-
en to specified torque.
Quick-release axle in
threaded bush
50 Nm
Tighten right axle clamping
screw 2 to the specified tight-
ening torque.
Clamping bolt in wheel
carrier
19 Nm
Remove the front-wheel stand.
without centre stand
OA
Remove the rear-wheel stand
with BMW Motorrad Integral
ABS II
OE
Insert the ABS sensor into its
bore and install screw 1.
8
112
z Maintenance

BMW K1300R Specifications

General

Displacement	1293 cc
Transmission	6-speed
Fuel Capacity	19 liters (5.0 US gal)
Seat Height	820 mm (32.3 in)
Bore x Stroke	80 mm x 64.3 mm
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft
Rear Brake	Single 265 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	217 kg (478 lb)
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	173 hp (129 kW) at 9, 250 rpm
Torque	140 Nm at 8, 250 rpm
Weight	243 kg
Front Suspension	Duolever
Rear Suspension	Paralever
Front Brake	Dual 320 mm discs, 4-piston calipers
