8 Installation
u
Observe all safety and warning information
(see"2Safety").
8.1
Installation information
T
The installation height of the appliance must be such
that the contents of the food support on the top shelf
level can be seen.
T
To prevent the appliance from shifting or tipping
over, it must be installed inside a fitted unit.
T
Handle recesses are provided at the sides for
carrying the appliance.
8.1.1
Fitted unit
T
The back panel of the kitchen unit must not be fitted
behind the appliance.
T
To prevent overheating, the appliance must not be
installed behind a decorative door.
T
An unobstructed ventilation cross-section of at least
160cm² must be provided in the unit.
T
A minimum distance of 30mm is to be maintained
between the back of the appliance and any adjacent
structure.
T
If two XBOs are installed one on top of the other, a
stable built-in shelf or appliance mounting brackets
must be provided for.
T
The appliance must not be installed underneath a hob.
Additional installation instructions for
Australia and New Zealand (AU/NZ)
T
The appliance may only be installed in a tall unit.
T
Minimum installation height: 850 mm from the
ground.
8.1.2
Fresh water connection
T
The appliance must have a mains water connection.
T
The appliance must be connected to the fresh water
supply (cold water) (3/4" connection thread).
T
The stopcock for the fresh water supply must be
easily accessible when the appliance is installed.
T
Only use the water supply hose provided. There must
be no kinks in the hose and it must not be shortened,
extended or replaced with another hose.
T
The water supply hose must not be flush-mounted.
Inlet water pressure
The inlet water pressure must be between 200kPa
(2bar) and 600kPa (6 bar). For Denmark, Finland,
Norway and Sweden, the maximum inlet water pressure
must be 1 MPa (10 bar).
T
If the pressure is greater than 600kPa (6bar), a
pressure regulator must be installed to ensure
seamless operation.
8.1.3
Waste water connection
T
The water outlet pipe must either be connected to a
surface or flush-mounted trap with a permanent hose
connection, or to the appliance connection on the
sink trap.
T
The waste water temperature can be up to 95 °C.
T
The trap must be easily accessible when the
appliance is installed.
T
Only use the water outlet hose provided. There must
be no kinks in the hose and it must not be shortened
or lengthened.
T
The water outlet hose must not be flush-mounted.
8.2
Scope of delivery
Scope of delivery Quant-
ity
X BO steam oven 1
X BO oven rack 1
X BO perforated stainless steel tray 1
X BO universal tray 1
XBO deep universal tray 1
X BO cleaning cartridge 1
X BO odour filter 1
X BO frame spacer (fitted) 1
Water supply hose 1
Water outlet hose 1
Drain filter 1
Hose clip 2
Unit mounting plate 2
Installation templates 1
Operating and installation instructions 1
Tab.8.1
Scope of delivery
