1 689 989 221 2015-12-11| Robert Bosch GmbH
Decommissioning | DCU 220 | 29 en
7. Decommissioning
7.1 Change of location
¶ If the DCU 220 is passed on, all the documentation
included in the scope of delivery must be handed over
together with the unit.
¶ The DCU 220 is only ever to be transported in the
original or equivalent packaging.
¶ Unplug the electrical connection.
¶ Heed the notes on initial commissioning.
7.2 Disposal and scrapping
1. Disconnect the DCU 220 from the mains and detach
the power cord.
2. Dismantle the DCU 220 and sort out and dispose of
the different materials in accordance with the appli-
cable regulations.
DCU 220, accessories and packaging should
be sorted for environmental-friendly recy-
cling.
¶ Do not dispose DCU 220 into household
waste.
Only for EC countries:
The DCU 220 is subject to the European
directive 2012/19/EC (WEEE).
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
¶ Make use of the local return and collection
systems for disposal.
¶ Proper disposal of DCU 220 prevents en-
vironmental pollution and possible health
hazards.
8. Technical Data
8.1 Temperature and humidity
Designation Value/range
Operating temperature 5 °C – 40 °C
41 °F – 104 °F
Storage Temperature -20 °C – 60 °C
-4 °F – 140 °F
Relative operating humidity 20 – 80 % non-
condensing
8.2 DCU 220
Characteristic Value/range
Display 11,6“ TFT, WXGA 1366x768
(1366 x 768)
Main-memory capacity 4 GB DDR3L
Hard disk (SSD) min. 256 GB
WLAN WLAN 802.11ac
Bluetooth Bluetooth 4.0 + EDR
Class 1
Camera At least 5 megapixels
Power supply unit 19 V +/- 20 %
Storage battery (Li-ion) 11,1 V/ 24 Wh
Dimensions without a carrying han-
dle
(H x W x D)
355 x 262 x 42 mm
1.2 x 0.9 x 0.14 inch
Weight with storage battery,
without power supply unit
2 kg
2.2 lb
Degree of protection IP 54
8.3 Power supply unit
Characteristic Value/range
Input voltage (AC) 100 - 240 VAC
Frequency 50 – 60 Hz
Input current 0,4 A
Output voltage (DC) 19 V +/- 20 %
Output current 3,42 A
8.4 Bluetooth Class 1
Wireless link Minimum range
Free field workshop environment 30 m
In passenger compartment, with ve-
hicle door or window open and en-
gine running
10 m
