Braun 07 Series User Manual

Page 36
U
N
F
O
L
D
(O
U
T
)
FO
L
D
(I
N
)
DO
W
N
UP
Lubrication Diagram and Chart
Specified (recommended) Available Braun
Lubricant Type Lubricant Amount Part No.
See the Maintenance/Lubrication Schedule for recommended applications per number of cycles or elapsed time.
Roll Stop Latch
(pivot/slide points)
Roll Stop Hinge
Detail C
Handrail
Pivot Pins (2)
LO
Roll Stop
Latch Lever
LO
Roll Stop
Latch
LO (See Detail C)
Platform Pivot Pin
(2 Points)
LO (See Detail B)
Platform
Fold Axles (2)
LO (See Detail B)
LO - Light Oil
DE - Door-Ease
Light Grease Lubriplate 14 oz.
(Multipurpose) Can
LG - Light Grease
UHMW
Bearing (4)
DE (See Detail A)
Inboard Roll Stop (IB)
Pivot Points
LO (See Detail B)
Rotating Pivot
Slide Arm Pivot Pins
LO (See Detail A)
Parallel Arm
Pivot Pins (8)
LO
Roll Stop Hinge
Detail A
UHMW
Bearings
Pivot Pin
Rotating Pivot
Slide Arm
Slide
Support
Arm
Lower
Fold
Arm
15807
15806
15805
Light Penetrating Oil LPS2, General Purpose 11 oz.
(30 weight or equivalent) Penetrating Oil Aerosol Can
Stainless Stick Door-Ease 1.68 oz.
Style (tube) Stick (tube)
Bridge Plate
(non-IB)
Pivot Points (2)
LO
Lift-Tite Latch
Roller Assemblies (2)
LO
Lift-Tite Latches
(Tower Pivot Points - 2)
LO
Lift-Tite Latch Dampening
Spring (2 springs - 4 Points)
LO
Roll Stop Hinge
Pivot Points (2)
LO (See Detail C)
Parallel Arm
Pivot Pins (8)
LO
(Pump Side Shown)
Detail B
Platform
Pivot Pin
Platform
Vertical Arm
Cotter Pin
Inboard
Roll Stop
Fold Lever
Inboard
Roll Stop
Bracket
Platform
Fold Axle
Spacer
Bushing
