Page 62
Item Qty. Description Part No. Part No.
1 Pump Module (complete), 12 Volt, Rear 915R7516IBQD 915R7516IBQD
1 1 Pump Assembly - Bridge, Prestolite (M268BP with Reservoir/with Backup pump) 25597A12V-A6 25597A12V-A6
2 2 Fitting, 7/16”-20 O-Ring Male / 7/16”-20 JIC 37° Male 24504 24504
3 1 Elbow, 7/16”-20 JIC 37° Female Swivel (1) / 7/16”-20 JIC 37° Male (2) 26579 26579
4 1 Switch, Pressure 26577 26577
5 1 Harness, Pressure Switch / Up - Fold Microswitch 29553A 29553A
61See Control Box Assembly and Harness Options ✘ See note below
71See Control Box Assembly and Harness Options ✘ See note below
8 1 Control Box, Bracket-mount (Items 9, 10 and 11) ✘ See note below 16970A 16970A
9 1 Control Box (only) ✘ See note below 16932 16932
10 1 Clip, Bracket-Mount ✘ See note below 16933 16933
11 3 Screw, #6-20 x 1-1/4", Pan Head, Phillips ✘ See note below 16945 16945
12 1 Face Plate and Switch Assembly ✘ See note below 17909A-05 17909A-05
13 1 Face Plate ✘ See note below 16931-05 16931-05
14 1 Switch, S.P.D.T., Rocker (Unfold/Fold) - Orange ✘ See note below 17332 17332
15 1 Switch, S.P.D.T., Rocker (Down/Up) - Red ✘ See note below 16942 16942
16 4 Screw, #6-20 x 3/4", Pan Head, Phillips ✘ See note below 24739 24739
17 1 Strain Relief (SR 7W-2) ✘ See note below (7A, 7B and 7C only) 11352 11352
18 1 Cover, Switch Box ✘ See note below 26798 26798
19 1 Plate, Backing / Mounting, Rear 975R0501 975R0501
20 1 Harness, Pump Module ✘ See note below 918R7914IBQD 915R7914IBQD
21 4 Snap Rivet, .122” x .197/.236", Nylon, Black ✘ See note below 29874 29874
22 1 Jumper, Interlock 15708A 15708A
23 1 Relay, 30 Amp, S.P.D.T., 12 Volt 18087 18087
24 1 Pop Rivet, SD64BS, 3/16" 11513 11513
25 1 Washer, #10 Flat 11541 11541
26 2 Washer, 5/16” Flat 10063 10063
27 1 Cable, Ground - 46" ✘ See note below 26161A 26161A
28 2 Bolt, 5/16”-18 x 1/2”, Nylock, Hex * See note below 10012 10012
29 2 Bolt, 5/16-18 x 3/4" w/Nylock Patch * See note below 29608 29608
30 1 Solenoid, Up - Prestolite Short / 100 Amp - 12V 28308 28308
31 1 Jumper, 16 Gauge 800-2000 800-2000
32 1 Diode Assembly, Up Solenoid 73906A 73906A
33 1 Power Cable, Millennium - Up Solenoid to Motor 29049 29049
34 1 Harness, Solenoid / Microswitch 29552A 29552A
35 1 Cable, Pump Module Hookup / Power 26082A-4 26082A-4
36 1 Harness, Up Solenoid / Circuit Breaker 25809A 25809A
37 1 Circuit Breaker, 5 Amp, Manual Reset 25736 25736
38 1 Stud, Power Feed 26084 26084
39 1 Cable, Lift Power, 37' with Loom ✘ See note below 205-0712-37 205-0712-37
40 1 Rubber Boot, Red ✘ See note below 82046 82046
41 1 Clamp, Hose 29663 29663
42 1 Diode, Green LED - Panel Mount 29545 29545
43 1 Receptacle, Clip on 28803 28803
44 1 Cover, Pump, 2pc. - Back / Bottom - Rear Pump 915R5513B 915R5513B
45 1 Handle, Pump - w/Grip 17206A 17206A
46 1 Cover, Pump, 2pc. - Top / Front Assembly - Rear Pump (Includes Items 47 - 57) 915R5513TA 915R5513TA
47 1 Cover, Pump, 2pc. - Top / Front - Rear Pump 915R5513T 915R5513T
48 1 Clip, Pump Handle - Top 915-5517 915-5517
49 1 Washer, Nylon, 1/4" I.D. x 11/16" O.D. x .030" 12690 12690
50 3 Rivet, Pop, SD43BS - 1/8" - .13/.19" 12954 12954
51 1 Clip, Pump Handle - Bottom 915-5518 915-5518
52 1 Stud, Wing Head - 1/4 Turn 28804 28804
53 1 Retainer, Push-On 28805 28805
54 1 Decal, Removal Instruction - Pump Handle (Not shown - see Decal Section) 29052 29052
55 1
Decal, Hydraulic Pressure Switch Instruction and Warning (Not shown - see Decal Section)
27154 27154
56 1 Decal, Manual Hand Pump Instruction
(Not shown - see Decal Section) 29082 29082
57 1 Decal, Pump Cover Installation / Removal (Not shown - see Decal Section) 29051 29051
58 1 Decal, Pressure Relief Warning (Not shown - see Decal Section) 22249 22249
59 1 Washer, 5/16" External Tooth 16368 16368
✘ Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
* Apply red #271 Thread Locker Loctite
®
to the three pump mounting bolts (items 28 and 29) if a blue nylon patch is not
present on the bolts when retrofitting an M268BP pump assembly. Loctite
®
is available from The Braun Corporation
under part number 11522-1.
Item Qty. Description Part No.
6A 1 Control Box Assembly (with Standard Quick-Disconnect Harness) ✘ See Note Below 900-0903AQD
6B 1 Control Box Assembly (with Armored Quick-Disconnect Harness) ✘ See Note Below 900-0903AQDA
6C 1 Control Box Assembly (with Coiled Quick-Disconnect Harness) ✘ See Note Below 900-0903AQDC
6D 1 Control Box Assembly (with 7' Long, 18 Ga., Quick-Disconnect Harness) ✘ See Note Below (not shown) 900-5903AQD
7A 1 Harness, Standard, Quick-Disconnect (without control box) ✘ See Note Below 900-0902AQD
7B 1 Harness, Armored, Quick-Disconnect (without control box) ✘ See Note Below 900-0902AQDA
7C 1 Harness, Coiled, Quick-Disconnect (without control box) ✘ See Note Below 900-0902AQDC
7D 1 Harness, 7' Long, 18 Ga., Quick-Disconnect (without control box) ✘ See Note Below (not shown) 900-5902AQD
Control Box Assembly and Harness Options
L918, L918IB L919, L919IB
L915, L915IB L917, L917IB
L916, L916IB
Rear Pump Module Parts List
