1 1 Base Plate Weldment 916R7148W30 916F7148W30 917R7148W33 917F7148W33 919R7148W34 919F7148W34
2 1 Bridge Switch Assembly 25463RA 25463FA 25463RA 25463FA 25463RA 25463FA
3 1 Pin, Platform Pivot 915U032430 915U032430 911-5324 911-5324 911-5324-31 911-5324-31
4 1 Platform Weldment 915R63050W 915R63050W 915R63350W 915R63350W 919R63450W 919R63450W
5 1 Block, Platform Stop - Bridging - Rear 25778 900-0311 25778 900-0311 25778 900-0311
6 1 Block, Platform Stop - Bridging - Front 900-0311 25778 900-0311 25778 900-0311 25778
7 1 Roll Stop (Extruded Aluminum) 915R4312-30 915R4312-30 915R4312-33 915R4312-33 915R4312-34 915R4312-34
8 1 Roll Stop Nose, Rubber 24603-30 24603-30 24603-33 24603-33 24603-34 24603-34
9 1 Bridge Plate 915U0146 915U0146 915U0147 915U0147 915U0147-34 915U0147-34
10 1 Plate, Backing/Mounting-Pump Module 975R0501 975F0501 975R0501 975F0501 975R0501 975F0501
11 1 Pump Cover, 2Pc, Top-Front Assy. 915R5513TA 915F5513TA 915R5513TA 915F5513TA 915R5513TA 915F5513TA
12 1 Pump Cover, 2Pc, Back-Bottom 915R5513B 915F5513B 915R5513B 915F5513B 915R5513B 915F5513B
13 1 Bracket, Mounting, Quiet-Ride 995-2392 995-2392 915-0392 915-0392 915-0392 915-0392
80 1 Rivet, Pop, SD64BS - 3/16" 11513
81 2 Bolt, 5/16-18 x 1 1/4", Low Soc. Hd. Cap Scr., Bk. 26327
82 2 Nut, 5/16-18, Top Lock, Black 28324BK
83 1 Screw, #8-32 x 1", Mach. Truss Head, Black 19912BK
84 2 Nut, #8-32, Hex 10777
85 2 Screw, 1/2-20 x 1 1/2", Set, Lock 18663
86 3 Edge Liner, 1/8" U-Molding, Yellow 24045R025.75
87 2 Slide, Platform, UHMW 900-0320
88 8 Screw, #8-18 x 1" Wafer Head, Self-Tap 14549
89 1 Cylinder, Roll Stop, Assembly 915-5318A
90 1 Pin, Platform Cylinder 915-0414
91 2 Ring, Snap, 1/2", External, .035” Thick 20946
92 1 Spacer, Flap Cylinder, .184" Thick 915-0416
93 1 Spacer, Flap Cylinder, .700" Thick 915-0415
94 1 Pivot, Roll Stop Cylinder, Front 990-0352
95 1 Washer, .4" I.D. x .810" O.D. x .12" 24536
96 1 Bolt, 3/8-16 x 3/4", Soc. Hd. Cap Screw, Bk. 26259
97 1 Adapter, Cylinder/Roll Stop Lever 915-0344
98 4 Adapter, Cylinder/Roll Stop Lever-Out 990-0341
99 4 Screw, #10-32 x 3/8", Flat Head, Hex 24537
100 1 Pivot, Roll Stop Lever 24550
101 1 Lever, Roll Stop Latch (Assembly #915-0345A) 915-0345
102 2 Bearing, Flange, 1/2" x 1/4" 24442
103 1 Latch, Roll Stop 915-0343R
104 1 Spacer, UHMW, Latch 950-7760
105 1 Spring, 1/4" x 1" Extension w/Hooks 10774
106 2 Bearing, Flange, 3/8" x 1/4" 24028
107 2 Pin, Clevis, 3/8" x 3", Black 24932BK
108 1 Tab, Roll Stop, Flap Cylinder 915-2367
109 1 Screw, 10-32 x 5/8", Pan Head Phillips, Thd. Cut 26714
110 2 Cotter Pin, 1/4" x 2", Black 15886BK
111 8 Fastener, J-Nut, #10-24 25776
112 8 Screw, #10-24 x 1/2", Button Head, Allen 25842
113 2 Bolt, 5/16-18 x 1/2", Nylock, Hex 10012
114 2 Bolt, 3/8-16 x 3/8", Nylock, Hex 29729
115 1 Holder, Owner's Manual - Clear 25715
116 3 Rivet, Pop, SD62BS-3/16"-.06"/.13" 11512
117 2 Tape, 1" Wide Single Face Foam x 11" (1 Shown) 82015R011
118 4 Tape, 1" Wide Single Face Foam x 8" (2 Shown) 82015R008
119 2 Tape, 1" Wide Single Face Foam x 14" (1 Shown) 82015R014
120 2 Washer, 5/16" Flat 10063
121 2 Cap, End, 1" I.D. x 1 1/4" O.D., Plastic 20474
122 6 Washer, .516" I.D. x 1" O.D. x .0269" 15328
123 1 Latch Weldment, Front 27013FW
124 1 Latch Weldment, Rear 27013RW
125 2 Ring, External Snap, Lock, 1/2" 13273
126 4 O-Ring, 5/16" I.D. x 1/16" 26614
127 2 Spring, Dampener, Retract 26963
128 4 Ring, External Snap, 5/16" 24570
129 2 Bolt, 1/4-20 x 1/2", Button Head Socket 15733
130 2 Roller Assembly 1000-2395A
131 2 Roller Retainer 915-5353
132 2 Washer, Finger Disc Springs 27276
133 3 Washer, 5/16" External Tooth 16368
134 1 Grommet, ID-.281", FR-.125", GD-.625", T-.375" 27725
135 1 Grommet, ID-.312", FR-.250", GD-.813", T-.500" 27726
136 3 Clamp, 1/4" ID, Nylon Loop, BLK 84396
137 2 Spacer, UHMW, Vertical Channel 995-0320
138 2 Bearing, Flange, 1" x 1/2", 16FDU08 28031
139 1 Retainer, Push-On 28805
140 1 Receptacle, Clip-On 28803
141 1 Diode, Green LED, Panel Mount 29545
142 1 Weldment, Microswitch, Slide Adjust, Front 990-2119WF
143 1 Weldment, Microswitch, Slide Adjust, Rear 990-2119WR
144 5 Screw, #4-40 x 3/4" R.D. H.D. 11483
145 1 Spacer, .125" I.D. x .250" O.D. x .325" 990-7128
146 1 Weldment, Microswitch Bracket 975-0120W
147 4 Bolt, 1/4-20 x 3/4", Flat Head, Soc Cap 18708
148 2
Clip, Cable, 1/2", Plastic 10092
14 2 Bolt, 5/16-18 x 3/4", Nylock 29608
15A 1 Parallel Arm Weldment, Top, Front 915-0437F
15B 1 Parallel Arm Assembly, Top, Front (w/Flanged Bearings) 915-0437FA
16A 1 Parallel Arm Weldment, Top, Rear 915-0437R
16B 1 Parallel Arm
Assembly , Top, Rear (w/Flanged Bearings) 915-0437RA
17A 2 Parallel Arm Weldment, Bottom 975-0458W
17B 2 Parallel Arm
Assembly , Bottom, (w/Flanged Bearings) 975-0458A
18 1 Handle Clip, Top 915-5517
19 1 Vertical Channel Weldment, Front 955F2448W
20 1 Vertical Channel Weldment, Rear 955R2448W
21 2 Handrail Weldment, ADA 916-0409W
22 2 Platform Pivot Arm Weldment 915-0441W
23 2 Cylinder C1514.3-9408
24 1 Pump Assembly (M268 with Backup Pump) 25597A12V-A6
25 2 Nut, 1/4-20, Nylock 14614
26 4 Washer, 1/4" Flat 10062
27 5 Washer, 1/4" I.D. x 11/16" x .030" - Nylon 12690
28 2 Bolt, 1/4-20 x 5", Hex, All Thread 29083
29 1 Handle Clip, Bottom 915-75518
30 4 Bushing, Microswitch 911-7125
31 2 Microswitch, Floor Level, Cupped 23184
32 3 Rivet, Pop, 1/8" - .13"/.19" 12954
33 7 Nut, #4-40 with Lock Washer 19537
34 2 Clamp, Insulate, 1 3/8" I.D. 29765
35 2 Grommet, Rubber, 1.25" I.D. 25916
36 1 Handle, Pump (w/Grip) 17206A
37 1 Stud, Wing Head 28804
38 8 Pin, Pivot Parallel Arm 917-0403
39 8 Washer, 1/2" Flat, Black Zinc 25346
40 8
Screw, 5/16-18 x 3/4", SHFS 25527
41 8 Screw, Drive #8 x 3/16" Long 24439BK
42 2 Washer, 14 Ga. Whale Pin 205-1791
43 2 Bearing, 1/2" O.D. x 3/8" I.D. x .150" Long 955-0102
44 2 Bolt, 3/8-16 x 3/4", Flanged, Button Head 25171
45 4 Nut, 3/8-16 Top Lock, Black 28339BK
46 2 Bolt, 3/8-16 x 3/4", Socket Head, Cap, Black 26259
47 16 Bearing, Flange, 3/4" x 3/8", 12FDU06 24011
48 8 Bushing, 3/4" I.D. x 1/2" 900-0456
49 2 Washer, 5/16", Lock 10068
50 1 Rivet, Pop, SD68BSLF-3/16"-.38"/.50" 15244
51 2 Bracket, Inner Side Panel Guide 915-0703
52 5 Rivet, Pop, SD66BS - 3/16" 14993
53 2 Bracket, Mounting, Quiet-Ride 915-0392
54 2 Bolt, 5/16-18 x 3/4", Button Hd. Socket Cap, Bk. 24440
55 2 Stow Block, Guided 28593
56 2 Bolt, 5/16-18 x 3/4", Carriage, Black 15858BK
57 4 Nut, 5/16-18, Hex 10058
58 2 Arm, Slide Support 915-0411
59 4 Spring, 3/4" x 5/12" Extension with Hooks 24281
60 8 Bearing, Flange, 3/4" x 1/4" 24012
61 2 Slide, Platform, Rotate 915-0407
62 4 Bearing, UHMW, Flat, 1.226" 205-1760
63 2 Pin, Pivot, Lower Arm 915-0413
64 8 Ring, Snap, 3/4", External 18657
65 4 Spacer, Handrail, UHMW 911-5301
66 4 Bolt, 3/8-16 x 3/4", Hex 12463
67 2 Grip, Handle, Yellow 19074
68 4 Bumper, Rubber, 31/32" O.D. 10950
69 2 Screw, #8-18 x 1/2", Self-Tap, Phillips 13583
70 2 Pin, Pivot, Handrail 900-0429
71 2 Screw, #4-40 x 5/8", Round Head 14810
72 1 Cover, Plastic, Parallel Arm, Fr - w/Tape 915-3704A
73 1 Cover, Plastic, Parallel Arm, Fr, Inside - w/Tape 915-3701A
74 1 Cover, Plastic, Parallel Arm, Rr, Inside - w/Tape 915-3703A
75 1 Cover, Plastic, Parallel Arm, Rr - w/Tape 915-3702A
76 2 Clip, Cable, 7/16", Plastic 15777
77 1 Clamp, Insulated, 5/8" I.D. 84070
78 4 Washer, #10 Flat 11541
79 7 Rivet, Snap, Black, .256/.295" Thick 26362
Item Qty. Description Part No.
Item Qty. Description L916 L916F L917 L917F L919 L919F
Part Numbers of Items Dedicated per Lift Model
Part Numbers of Items Identical on All Lift Models
48" Floor-To-Ground Fixed Inboard Roll Stop
Non-IB Lift Models Repair Parts List
