Item Qty. Description L915 L915F L918 L918F
Part Numbers of Items Dedicated per Lift Model
80 1 Rivet, Pop, SD64BS - 3/16" 11513
81 2 Bolt, 5/16-18 x 1 1/4", Low Soc. Hd. Cap Scr., Bk. 26327
82 2 Nut, 5/16-18, Top Lock, Black 28324BK
83 1 Screw, #8-32 x 1", Mach. Truss Head, Black 19912BK
84 2 Nut, #8-32, Hex 10777
85 2 Screw, 1/2-20 x 1 1/2", Set, Lock 18663
86 3 Edge Liner, 1/8" U-Molding, Yellow 24045R025.75
87 2 Slide, Platform, UHMW 900-0320
88 8 Screw, #8-18 x 1" Wafer Head, Self-Tap 14549
89 1 Cylinder, Roll Stop, Assembly 915-5318A
90 1 Pin, Platform Cylinder 915-0414
91 2 Ring, Snap, 1/2", External, .035” Thick 20946
92 1 Spacer, Flap Cylinder, .184" Thick 915-0416
93 1 Spacer, Flap Cylinder, .700" Thick 915-0415
94 1 Pivot, Roll Stop Cylinder, Front 990-0352
95 1 Washer, .4" I.D. x .810" O.D. x .12" 24536
96 1 Bolt, 3/8-16 x 3/4", Soc. Hd. Cap Screw, Bk. 26259
97 1 Adapter, Cylinder/Roll Stop Lever 915-0344
98 4 Adapter, Cylinder/Roll Stop Lever-Out 990-0341
99 4 Screw, #10-32 x 3/8", Flat Head, Hex 24537
100 1 Pivot, Roll Stop Lever 24550
101 1 Lever, Roll Stop Latch (Assembly #915-0345A) 915-0345
102 2 Bearing, Flange, 1/2" x 1/4" 24442
103 1 Latch, Roll Stop 915-0343R
104 1 Spacer, UHMW, Latch 950-7760
105 1 Spring, 1/4" x 1" Extension w/Hooks 10774
106 2 Bearing, Flange, 3/8" x 1/4" 24028
107 2 Pin, Clevis, 3/8" x 3", Black 24932BK
108 1 Tab, Roll Stop, Flap Cylinder 915-2367
109 1 Screw, 10-32 x 5/8", Pan Head Phillips, Thd. Cut 26714
110 2 Cotter Pin, 1/4" x 2", Black 15886BK
111 8 Fastener, J-Nut, #10-24 25776
112 8 Screw, #10-24 x 1/2", Button Head, Allen 25842
113 2 Bolt, 5/16-18 x 1/2", Nylock, Hex 10012
114 2 Bolt, 3/8-16 x 3/8", Nylock, Hex 17633
115 1 Holder, Owner's Manual - Clear 25715
116 3 Rivet, Pop, SD62BS-3/16"-.06"/.13" 11512
117 2 Tape, 1" Wide Single Face Foam x 11" (1 Shown) 82015R011
118 4 Tape, 1" Wide Single Face Foam x 8" ( 2 Shown) 82015R008
119 2 Tape, 1" Wide Single Face Foam x 14" (1 Shown) 82015R014
120 2 Washer, 5/16" Flat 10063
121 2 Cap, End, 1" I.D. x 1 1/4" O.D., Plastic 20474
122 6 Washer, .516" I.D. x 1" O.D. x .0269" 15328
123 1 Latch Weldment, Front 27013FW
124 1 Latch Weldment, Rear 27013RW
125 2 Ring, External Snap, Lock, 1/2" 13273
126 4 O-Ring, 5/16" I.D. x 1/16" 26614
127 2 Spring, Dampener, Retract 26963
128 4 Ring, External Snap, 5/16" 24570
129 2 Bolt, 1/4-20 x 1/2", Button Head Socket 15733
130 2 Roller Assembly 1000-2395A
131 2 Roller Retainer 915-5353
132 2 Washer, Finger Disc Springs 27276
133 3 Washer, 5/16" External Tooth 16368
134 1 Grommet, ID-.281", FR-.125", GD-.625", T-.375" 27725
135 1 Grommet, ID-.312", FR-.250", GD-.813", T-.500" 27726
136 3 Clamp, 1/4" ID, Nylon Loop, BLK 84396
137 2 Spacer, UHMW, Vertical Channel 995-0320
138 2 Bearing, Flange, 1" x 1/2", 16FDU08 28031
139 2 Clip, Cable, 1/2", Plastic 10092
140 1 Stud, Wing Head 28804
141 1 Retainer, Push-On 28805
142 1 Receptacle, Clip-On 28803
143 1 Diode, Green LED, Panel Mount 29545
144 1 Weldment, Microswitch, Slide Adjust, Front 990-2119WF
145 1 Weldment, Microswitch, Slide Adjust, Rear 990-2119WR
146 5 Screw, #4-40 x 3/4" RD. HD. 11483
147 1 Spacer, .125" I.D. x .250" O.D. x .375" 990-7128
148 1 Weldment, Microswitch Bracket 975-0120W
14 4 Bolt, 1/4-20 x 3/4", Flat Head, Soc Cap 18708
15A 1 Parallel Arm Weldment, Top, Front 915-0422F
15B 1 Parallel Arm Assembly, Top, Front (w/Flanged Bearings) 915-0422FA
16A 1 Parallel Arm Weldment, Top, Rear 915-0422R
16B 1 Parallel Arm
Assembly , Top, Rear (w/Flanged Bearings) 915-0422RA
17A 1 Parallel Arm Weldment, Bottom 975-0457W
17B 1 Parallel Arm Assembly, Bottom (w/Flanged Bearings) 975-0457A
18 2 Bolt, 5/16-18 x 3/4" Nylock 29608
19 1 Vertical Channel Weldment, Front 955F2442W
20 1 Vertical Channel Weldment, Rear 955R2442W
21 2 Handrail Weldment, ADA 915-0409W
22 2 Platform Pivot Arm Weldment 915-0424W
23 2 Cylinder C1514.3-9407
24 1 Pump Assembly (M268 with Backup Pump) 25597A12V-A6
25 2 Nut, 1/4-20, Nylock 14614
26 4 Washer, 1/4" Flat 10062
27 5 Washer, 1/4" I.D. x 11/16" x .030" - Nylon 12690
28 2 Bolt, 1/4-20 x 5", Hex, All Thread 29083
29 1 Handle Clip, Top 915-5517
30 4 Bushing, Microswitch 911-7125
31 2 Microswitch, Floor Level, Cupped 23184
32 1 Handle Clip, Bottom 915-5518
33 7 Nut, #4-40 with Lock Washer 19537
34 2 Clamp, Insulate, 1-3/8" I.D. 29765
35 2 Grommet, Rubber, 1.25" I.D. 25916
36 1 Handle, Pump (w/Grip) 17206A
37 3 Rivet, Pop, 1/8"-.13"/.19" 12954
38 8 Pin, Pivot Parallel Arm 917-0403
39 8 Washer, 1/2" Flat, Black Zinc 25346
40 8
Screw, 5/16-18 x 3/4", SHFS 25527
41 8 Screw, Drive #8 x 3/16" Long 24439BK
42 2 Washer, 14 Ga. Whale Pin 205-1791
43 2 Bearing, 1/2" O.D. x 3/8" I.D. x .150" Long 955-0102
44 2 Bolt, 3/8-16 x 3/4", Flanged, Button Head 25171
45 4 Nut, 3/8-16 Top Lock, Black 28339BK
46 2 Bolt, 3/8-16 x 3/4", Socket Head, Cap, Black 26259
47 16 Bearing, Flange, 3/4" x 3/8", 12FDU06 24011
48 8 Bushing, 3/4" I.D. x 1/2" 900-0456
49 2 Washer, 5/16", Lock 10068
50 1 Rivet, Pop, SD68BSLF-3/16"-.38"/.50" 15244
51 2 Bracket, Inner Side Panel Guide 915-0703
52 5 Rivet, Pop, SD66BS - 3/16" 14993
53 1 Bracket, Mounting, Quiet-Ride 915-0392
54 2 Bolt, 5/16-18 x 3/4”, Button Hd. Socket Cap, Bk. 24440
55 2 Stow Block, Guided 28593
56 2 Bolt, 5/16-18 x 3/4", Carriage, Black 15858BK
57 4 Nut, 5/16-18, Hex 10058
58 2 Arm, Slide Support 915-0411
59 4 Spring, 3/4" x 5/12" Extension with Hooks 24281
60 8 Bearing, Flange, 3/4" x 1/4" 24012
61 2 Slide, Platform, Rotate 915-0407
62 4 Bearing, UHMW, Flat, 1.226" 205-1760
63 2 Pin, Pivot, Lower Arm 915-0413
64 8 Ring, Snap, 3/4", External 18657
65 4 Spacer, Handrail, UHMW 911-5301
66 4 Bolt, 3/8-16 x 3/4", Hex 12463
67 2 Grip, Handle, Yellow 19074
68 4 Bumper, Rubber, 31/32" O.D. 10950
69 2 Screw, #8-18 x 1/2", Self-Tap, Phillips 13583
70 2 Pin, Pivot, Handrail 900-0429
71 2 Screw, #4-40 x 5/8", Round Head 14810
72 1 Cover, Plastic, Parallel Arm, Fr - w/Tape 915-3704A
73 1 Cover, Plastic, Parallel Arm, Fr, Inside - w/Tape 915-3701A
74 1 Cover, Plastic, Parallel Arm, Rr, Inside - w/Tape 915-3703A
75 1 Cover, Plastic, Parallel Arm, Rr - w/Tape 915-3702A
76 2 Clip, Cable, 7/16", Plastic 15777
77 1 Clamp, Insulated, 5/8" I.D. 84070
78 4 Washer, #10 Flat 11541
79 7 Rivet, Snap, Black, .256/.295" Thick 26362
Item Qty. Description Part No.
Item Qty. Description Part No.
Part Numbers of Items Identical on All Lift Models
42" Floor-To-Ground Fixed Inboard Roll Stop
Non-IB Lift Models Repair Parts List
1 1 Base Plate Weldment 915R7142W30 915F7142W30 918R7142W33 918F7142W33
2 1 Bridge Switch Assembly 25463RA 25463FA 25463RA 25463FA
3 1 Pin, Platform Pivot 915U032430 915U032430 911-5324 911-5324
4 1 Platform Weldment 915R63050W 915R63050W 915R63350W 915R63350W
5 1 Block, Platform Stop - Bridging - Rear 25778 900-0311 25778 900-0311
6 1 Block, Platform Stop - Bridging - Front 900-0311 25778 900-0311 25778
7 1 Roll Stop (Extruded Aluminum) 915R4312-30 915R4312-30 915R4312-33 915R4312-33
8 1 Roll Stop Nose, Rubber 24603-30 24603-30 24603-33 24603-33
9 1 Bridge Plate 915U0145 915U0145 915U0148 915U0148
10 1 Plate, Backing/Mounting-Pump Module 975R0501 975F0501 975R0501 975F0501
11 1 Pump Cover, 2Pc, Top-Front Assy. 915R5513TA 915F5513TA 915R5513TA 915F5513TA
12 1 Pump Cover, 2Pc, Back-Bottom 915R5513B 915F5513B 915R5513B 915F5513B
13 1 Bracket, Mounting, Quiet-Ride 995-2392 995-2392 915R0392 915F0392
