3. INST
ALLA
TION
12
KE-484C
3-12.
Piping
Connect air tubes in accordance w
ith
the identified
numbers in the
figure.
*
Light work clamp
mode can be used by
changing over
the
air tube connections of w
ork clamp cy
linders.
(Refer to “14. Setting
the work clamp mode”.)
3159Q
Thread take-up
cylinder
Work clamp cylinder R
Tension release cy
linder
Thread trimmer
cylinder
Thread wiper cylind
er
Work clamp cylinder L
3160Q
17
