2. SPECIFICATIONS
2
KE-484C
2. SPECIFICATIONS
2-1. Specifications
Main use Seat Belt
Stitch formation Single needle lock stitch
Maximum sewing speed 2,200 rpm (Pitch 3 mm)
Maximum pattern size 100 × 60 mm max.
Feed mechanism R-θ intermittent feed mechanism (pulse-motor driven mechanism)
Stitch length 0.1 - 10.0 mm
Number of stitches Variable
Maximum stitch number 20,000 stitches (including 10,000 stitches which can be added)
Work clamp lifter Pneumatic type
Work clamp height 25 mm max.
Rotary hook Treble hook
Needle DP × 17 #25
Wiper device Standard equipment
Thread trimmer device Standard equipment
Thread take-up device Standard equipment
Safety device built-in stopping mechanism
Data storage method P-ROM (Any sewing pattern can be added using PS-3000.)
Number of user programs 16
Number of cycle programs 4
Number of stored data
Up to 100 patterns can be added. Total number of stitches of stored data
which can be added is within 10,000.
Motor Three-phase 400W induction motor
Weights
Machine head: 56 kg, Operation panel: 0.6 kg,
Control box: 9 - 19 kg (depending on destination)
Power source
Single-phase 110, 220 - 230, 240V
3-phase 220-230, 380, 400V
Maximum electric power consumption; 600VA
If you want to sew a pattern, you can create your original pattern using the PS-3000.
Consult with your local Brother Sales Office for details.
Note when creating additional data
When sewing data with a small number of stitches (15 stitches or less) is sewn repeatedly (short cycle operation), the upper
shaft motor may overheat and the “E-20” error code may be generated.
