12. CHANGING FUNCTIONS USING THE DIP SWITCHES
45
KE-484C
12. CHANGING FUNCTIONS USING THE DIP SWITCHES
12-1. Operation panel DIP switches
The functions shown in the table below can be changed by
means of these DIP switches (1).
* All DIP switches are set to OFF at the time of shipment.
Note:
Always turn off the power before setting the DIP switches.
Switch Motion when set to ON
DIPA-1 Presser does not automatically lift after sewing is completed.
DIPA-2 Pedal mode is switched.
See “14. Setting the presser mode”
DIPA-3 User program mode is available.
DIPA-4 −
DIPA-5 The presser does not rise automatically when a split is found.
DIPA-6
Displays the enlargement/reduction ratio in millimeter units instead of as a percentage. (After
changing this setting, be sure to carry out the auto-clear operation by referring to page 42.)
DIPA-7 Enlargement of pattern size is not available.
DIPA-8 Program number is fixed.
0176Q
2586Q
