18
Recharging the Battery
Recharge Level
0–50%
50–75%
75-90%
90% or higher
Red lamp
Blinks once per second
Blinks twice per second
Blinks three times per
second
Stays on
Connect the power cord.
•
Connect the power cord to the charger.
•
Connect the power plug to an AC
outlet.
1
Remove the cover.
•
If you remove the battery from the
camera, be sure to reattach the cover
to protect against short circuit.
2
<
–
> mark
Attach the battery.
•
Align the battery’s top edge with the
<
–
> mark on the charger. While
pressing down the battery, slide it in
the direction of the arrow.
•
To detach the battery, follow the above
procedure in reverse.
3
Recharge the battery.
s
When the battery is attached to the
charger, recharging starts
automatically and the red lamp starts
blinking.
s
A completely exhausted battery
takes about 90 minutes to almost
fully recharge.
4
* The numbers around red lamp and the
blinking frequency correspond to the table
above.
