Canon iR6000 Service Handbook

CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-19
3.3 Mounting the Drum Cleaning Blade
3.3.1 Removing the Cleaning Blade
1) Slide out the process unit from the ma-
chine. (See the Printer Manual : Chap.4
> 7.3 "Process Unit".)
2) Remove the primary charging assembly.
3) Disconnect the connector [1] of the AC
line of the drum heater.
4) Remove the four mounting screws [2],
and detach the cleaning blade assembly
[3].
F02-203-09
5) Remove the E-ring [4] from under the
cleaning blade assembly, and detach the
pressure spring [5].
F02-203-10
[1]
[2]
[3]
[5]
[4]

Canon iR6000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan
Print Speed	60 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Paper Sizes	A3, A4, B4, B5
Warm-Up Time	30 seconds
Multiple Copies	Up to 999
Magnification	25-400%
Copy Speed	60 ppm (A4)
