Canon Laser Shot LBP2900 User Manual

Windows Firewall
7-8
Appendix
7
Windows Firewall
Windows Firewall is a feature of Windows XP Service Pack 2 and other operating
systems that protects your computer by blocking unauthorized access over the
network.
If using the printer with an operating system equipped with Windows Firewall, you
need to set Windows Firewall to unblock communications.
You need to perform the following procedure on the print server (the computer that
is directly connected to the printer) and the clients (the computers that accesses
the printer via the network).
WARNING
If you want to copy the [CAPT Windows Firewall Utility] to your hard disk to run
it, copy all of the files (CNAB4FW.EXE, CAPTRGFW.DLL, CNAB4FW.INI) from the
[WF_UTIL] folder on the supplied "LBP2900 User Software" CD-ROM to your
hard disk.
Setting See
Print server
■ Installing the CAPT software from CD-ROM Setup:
Click [Yes] on the [Warning] dialog box that is displayed during
installation, and follow the instructions to configure Windows
Firewall to unblock communication with client computers.
p. 3-6
■ When installing the CAPT Software from the [Printers and
Faxes] folder or the [Printers] folder/When installing the
CAPT Software from [Windows Explorer]:
Use the [CAPT Windows Firewall Utility] to configure Windows
Firewall to unblock communication with client computers.
p. 7-9
Clients
Configure Windows Firewall to unblock communication with the
print server.
p. 7-12

Canon Laser Shot LBP2900 Specifications

General

Print Technology	Laser
Print Speed	12 ppm (A4)
Paper Handling	150-sheet input tray
Connectivity	USB 2.0
Memory	2 MB
Dimensions	370 x 251 x 217 mm
Weight	5.7 kg
Supported Paper Types	Plain Paper, Heavy Paper, Transparency, Label, Envelope
Operating System Support	Linux
Warm-up Time	0 seconds
First Print Out Time	9.3 seconds
Paper Size	A4, Letter, Legal
Power Consumption	259 W (Printing), 2 W (Standby)
Print Resolution	2400 x 600 dpi
