LV-7292A/LV-7297A/LV-7392A/LV-7393A/LV-7398A/LV-8227A/LV-7292M/LV-7297M/LV-8227M
Expand Serial Command Functional Specifications
-2-
２．Serial Interface Specification
2.1 Transfer Specification
Item Specification
Synchronous System Asynchronous
Transmission Speed 9600 / 19200
Data Length 8 bit
Parity N/A
Stop Bit 1
Flow Control N/A
Note1) Transmission Speed: initial setting value is 19200
Note2) Transmission Speed can be changed in service mode.
2.2 Connection
Dedicated serial cable must be used for a connection to a computer and a projector.
PC Projector
COM 1 Control Port
(D-Sub 9 Pin) (D-Sub 9 Pin)
