Important
The area (A) indicated in the figure below may be splattered with ink. It does not affect the
performance of the machine.
Do not touch the area (A). The machine may not print properly if you touch it.
Operation Panel
(1)
ON button (Power lamp)
Turns the power on or off. Lights or flashes green to indicate the power status. Before turning on the
power, make sure that the Document Cover is closed.
Important
Disconnecting the power plug
When disconnecting the power plug after turning off the power, be sure to confirm that
the
ON
button is not lit. If the power plug is disconnected from the wall outlet while the
ON
button is lit or flashing, the machine may become unable to print properly since the Print
Head is not protected.
If the power plug is disconnected, the date/time settings as well as all documents stored in
memory will be lost. Send an unsent fax or print a necessary document when the power
plug is disconnected.
Note
The machine cannot receive faxes when the power is turned off.
The power cannot be turned off while the machine is sending or receiving a fax, or when
there are unsent faxes in the machine's memory.
(2)
COPY button
Switches the machine to copy mode.
(3)
FAX button
Switches the machine to fax mode.
(4)
SCAN button
Switches the machine to scan mode.
(5)
Menu button
Displays the menu items.
(6)
Settings button
Page 10 of 817 pagesMain Components
