Inside the Printer
17
Printer Parts and Their Functions
Inside the Printer
Print Head Holder
Install the print head here.
Print Head Lock Lever
Locks the print head into the holder.
Once the print head is installed, do not touch this lever.
Paper Thickness Lever
Adjusts the gap between the print head and the surface of the printing paper.
