Setting Page
105
JPEG
You can configure settings for the quality and size of JPEG video transmitted from the camera, as well as, the video size
when recording the camera video.
The video sizes that can be set or selected depend on the [Video Size Set] setting.
[Video Quality]
Select the video quality transmitted from the camera for each size in a video size set.
Greater values have higher quality.
[Video Quality: Digital PTZ]
Select the video quality for digital PTZ.
[Video Size: video Transmission]
Select the default video size transmitted from the camera when no video size has been specified by the Viewer.
[Maximum Frame Rate: Video Transmission]
Limit the maximum frame rate per second transmitted to reduce the viewer load. Up to 30 frames per second can be set.
[Video Size: Upload / Memory card]
Select the size of video when using the upload function (P. 156) or when recording to a memory card (P. 215).
Set whether to upload a video or record it to a memory card with [Video Record] > [Upload] or [Memory Card] > [Video
Record Action] (P. 156).
H.264(1)
Settings for H.264(1) video transmitted from the camera.
The video sizes that can be selected depend on the [Video Size Set] setting.
[Video Size]
Select the size of the video transmitted from the camera.
[Bit Rate Control]
Set the video bit rate.
If you select [Use bit rate control], please set [Target Bit Rate (kbps)]. If you select [Do not use bit rate control], please set
[Video Quality].
[Target Bit Rate (kbps)]
You can select the target bit rate if [Bit Rate Control] is set to [Use bit rate control].
[Video Quality]
You can select the video quality if [Bit Rate Control] is set to [Do not use bit rate control].
Greater values have higher quality.
[Video Size Set] Category Aspect Ratio
[1920 x 1080 / 960 x 540 / 480 x 270] 1080p 16:9
[1280 x 720 / 640 x 360 / 320 x 180] 720p 16:9
[1280 x 960 / 640 x 480 / 320 x 240] 4:3 4:3
Changing the [Video Size Set] selection and clicking [Apply and reboot] will disconnect all connections and then change all the video
sizes. Consequently, users connected to the camera must reconnect.
If the [Video Size Set] selection is changed, review the following settings and check the operation.
– ADSR (P. 140)
– Privacy Mask (P. 143)
– Intelligent Function (P. 169)
– Preset (P. 131)
– View Restriction (P. 128)
– Camera Angle (P. 47)
R13 R12
R12 M50
H651
M50
H652 H651
