Setting the Camera Angle
47
Select [Camera] > [Camera Angle] on the Setting Page to set pan, tilt, zoom, rotation and focus.
[Camera Angle] can be also launched from the Camera Management Tool. For details, please refer to “Camera Management Tool User
Manual”.
Camera Angle Screen Composition
(1) Video Display Area
Camera video is displayed here.
(2) Control Assist Display
Displays the available directions for the camera with dotted lines when performing pan/tilt operations.
(3) [Pan] Buttons
Pan the camera.
(4) [Tilt] Buttons
Tilt the camera.
(5) [Zoom] Buttons
Zoom the camera.
(6) [Rotation] Buttons
Rotate the camera.
(7) [Rotation] Slider
Click on the slider or drag the slider to rotate the camera angle.
(8) [Reconnect] Buttons
Reconnects to the camera. Can be operated when not connected to the camera.
Setting the Camera Angle
• When starting to set the camera angle, the Viewers and recording software connected to the camera are disconnected.
• Connections to a single camera are limited to 30 minutes. Since the camera is automatically disconnected after 30 minutes elapse,
click the [Reconnect] button to reconnect to the camera if you have not finished setting the camera angle.
• Multiple computers cannot simultaneously connect to a single camera, using the [Camera Angle] tool.
(3)
(7)
(4)
(5)
(6)
(14)(4)
(1)
(2)
(3)
(9)
(15)
(8)
(10)
(13)
(12)
(11)
