Canon XC10 User Manual

79
Recording Audio
Menus
Table of Contents Index
Settings for each audio scene
NOTES
•[„ Custom Setting] is not available when the shooting mode is set to N. After setting [Audio Scene] to
[„ Custom Setting], if the shooting mode is then set to N, this setting will change to [
‘ Standard].
• To reproduce louder and quieter sounds in music more faithfully, we recommend that you first adjust the audio
recording level (refer to the following section). To reproduce the linearity of the music even more faithfully, we
recommend that you select the [„ Custom Setting] audio scene and adjust the audio settings to match those
of the [’ Music] audio scene except set [Audio Compressor] to [j Off].
Audio Recording Level
You can adjust the audio recording level of the built-in microphone or an external microphone connected to the
MIC terminal.
1 Touch [FUNC.] and then touch [Mic Level].
2 Touch [ ] to set the audio recording level to manual.
• Touch [ ] instead to return the camcorder to automatic audio recording level.
3Touch [Ï]/[Ð] to adjust the audio recording level as necessary and then touch [X].
• As a guideline, adjust the audio recording level so that the audio level meter will go to the right of the -10 dB
mark only occasionally.
[ ‘ Standard] [’ Music] [ Festival][‚ Speech] [ Meeting]
[“ Forests
and Birds]
[” Noise
Suppression]
[„ Custom
Setting]
[Mic level]
[
Manual]: 70
[
Manual]: 70
[
Manual]: 70
[
Manual]: 86
[
Manual]: 94
[
Manual]: 80
[
Manual]: 70
Selected by
user (A 79)
[Built-in Mic
Wind Screen]
[H Auto
(High)]
[L Auto (Low)
ë]
[L Auto (Low)
ë]
[H Auto
(High)]
[H Auto
(High)]
[H Auto
(High)]
[H Auto
(High)]
Selected by
user (A 80)
[Built-in Mic
Att.]
[k
Automatic]
[k
Automatic]
[k
Automatic]
[k
Automatic]
[k
Automatic]
[k
Automatic]
[k
Automatic]
Selected by
user (A 81)
[Built-in Mic
Freq.
Response]
[h
Normal]
[ê Boost
HF+LF
Range]
[h
Normal]
[é Boost
MF Range]
[é Boost
MF Range]
[è Low
Cut Filter]
[è Low
Cut Filter]
Selected by
user (A 81)
[Built-in Mic
Directionality]
[h
Normal]
[î Wide] [î Wide]
[í
Monaural]
[î Wide] [î Wide]
[í
Monaural]
Selected by
user (A 82)
[Audio
Limiter]
[i On] [i On] [i On] [i On] [i On] [i On] [i On]
Selected by
user (A 83)
[Audio
Compressor]
[L Low] [L Low] [L Low] [j Off] [H High] [L Low] [j Off]
Selected by
user (A 84)
Manual audio level adjustment
Audio level indicator
Audio level adjustment bar
Current audio recording level

Canon XC10 Specifications

General

Sensor type	CMOS
Total megapixels	13.36 MP
Optical sensor size	- \
Effective megapixels (image)	12 MP
Effective megapixels (movie)	8.29 MP
Filter size	58 mm
Digital zoom	0 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	8.9 - 89 mm
Interchangeable lens	-
Image stabilizer type	Hybrid Image Stabilization (HIS)
Maximum aperture number	2.8
Minimum aperture number	5.6
Focal length (35mm film equivalent)	27.3 - 273 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CFast, SD, SDHC, SDXC
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
ISO sensitivity	20000, 160, 320, 640, 1250, 2500, 5000, 10000
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1030000 pixels
Viewfinder type	Optical
Camcorder type	Handheld camcorder
Minimum illumination	0.05 lx
Product color	Black
Supported video modes	1080p, 2160p, 720p
Video formats supported	XF-AVC
Maximum video resolution	3840 x 2160 pixels
Image formats supported	JPG
Maximum image resolution	4000 x 3000 pixels
Audio system	stereo
PCM digital audio	16-bit/48 kHz
Audio formats supported	LPCM
Microphone connectivity	3.5 mm
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Battery type	LP-E6N
Battery voltage	7.2 V
Battery capacity	1865 mAh
Battery life (max)	- h
Number of diaphragm blades	8
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
Cables included	HDMI, USB

Weight and Dimensions

Depth	102 mm
Width	125 mm
Height	122 mm
Weight	930 g
