Carel c.pCO User Manual

58
ENG
c.pCO sistema +0300057EN rel. 1.2 - 29.05.2017
11.1 Devices that can be connected to the c.pCO
Device seriale zero -
pLAN o display port
seriale one - BMS1
seriale two
– FBus 1
seriale three -
BMS 2
seriale four -
FBus 2
USB Master
(Host)
USB Slave
(Device)
Ethernet
connector J11 connector J10
connector
J3 Disp.
PCOS004850
PCO10000F0
PCO10W0WB0
PCO10W0BA0
PCOS00KXB0
PCO100FD10
PCOS00KXF0
connector J25
connector J6
BMS
connector J26
(and J23 su
L - XL)
connector J4
FBus
pGD1 terminal x x
PCOT - pCOI terminal
(pGD1 version only)
xx
pLDPRO terminal x x
EVD Evolution x x x
CAREL Slave devices (485) x x x
pCOexp 485 x x x
c.pCOe xxx
PlantVisorPRO x x x x x x x x
PlantWatchPRO x x x x x x x x
PCGate x x x x x x x x
WebGate x x x x x x x x
GATEWAY**0 x x x x x x x x
LON - Echelon FTT10 x
BACnet MS/TP (RS485)(*) x x x x
Konnex x x
HTTP client x x
BACnet/Ethernet x
BACnet/IP x x
SNMP v1, SNMP v2C x
Modbus TCP/IP x x
Modbus supervisor (RTU) x x x x x
Modbus Slave devices x x x
Power + xxx
Pendrive (USB ash drive ) x
PC Mass Storage x
th-Tune terminal x x x
pGD Touch x x x x x x x
Tab. 11.a
(*) the BACnet MS/TP protocol is available on BMS2 / FBus2 / Ethernet, if the additional license is enabled on the controller (the protocol is active on 1 port at a time).
12. TECH NICAL SPECIFICATIONS
12.1 c.pCO technical specifications
Physical specications
Dimensions
MINI panel 147.3 x 81.3 x 70.5 mm
4 DIN modules 70 x 110 x 63 mm
SMALL 13 DIN modules 110 x 227,5 x 60 mm
MEDIUM, LARGE, EXTRALARGE 18 DIN modules 110 x 315 x 60 mm
BUILT-IN DRIVER 18 DIN modules 110 x 315 x 75 mm
Plastic case
Assembly on DIN rail in accordance with DIN 43880 and IEC EN 50022 / or panel
Material technopolymer
Flammability V2 (UL94) and 850 °C (in accordance with IEC 60695)
Ball pressure test temperature 125 °C
Resistance to creeping current ≥ 250 V
Colour White RAL 9016
Built-in terminal PGD1 (132x64 pixel) with backlit keypad
Other specications
Operating conditions c.pCO: P+5**SE***0** (w/o built-in terminal): -40T70 °C, 90% RH non-condensing(*)
c.pCOmini: P+(D)*******0** (w/o built-in terminal): -40T70 °C, 90% RH non-cond.
c.pCO:P+5**SE***E** (with built-in term.): -20T60 °C, 90% RH non-condensing
c.pCOmini: P+(D,P)*******E** (with built-in term.): -20T60 °C, 90% RH non-cond.
(*) with Ultracap module tted: -40T60°C
Storage conditions
c.pCO: P+5**SE***0** (w/o built-in terminal): -40T70 °C, 90% RH non-condensing
c.pCOmini: P+(D)*******0** (w/o built-in terminal): -40T70 °C, 90% RH non-cond.
c.pCO: P+5**SE***E** (with built-in terminal): -30T70 °C, 90% RH non-cond.
c.pCOmini: P+(D,P)*******E** (with built-in terminal): -30T70 °C, 90% RH non-cond.
Ingress protection
c.pCO: IP20 on the front panel only
c.pCOmini: P+P********** (panel): IP 65; P+D********** (DIN): IP 40
Controller pollution class 2
Class according to protection against electric
shock
c.pCO: to be integrated into Class I and/or II equipment in versions without valve driver, Class I in versions with
valve driver
c.pCOmini: to be integrated into Class I and/or II equipment (Basic/Enhanced) - Class I (High-End)
PTI of insulating materials PCB: PTI 250 V; insulating material: PTI 175
Period of electrical stress across the insulating parts long
Type of action 1C; 1Y for SSR versions
Type of disconnection or microswitching microswitching
Heat and re resistance category Category D (UL94-V2)
Ageing characteristics (operating hours) 80,000
No. of automatic operating cycles 100,000 (EN 60730-1); 30,000 (UL60730)
Rated impulse voltage c.pCO: 2500V
