APPENDIX B: SystemVut Controller Text P oint Reference
SystemVu Display Name = MODE
SystemVu Text point = MODETEXT
SystemVu Numeric point = SYS_MODE
MODETEXT
SYS_MODE
OFF 1
COOL 2
HEAT 3
VENT 4
TEST 5
SystemVu Display Name = SUB---MODE
SystemVu Text poin t = SUBMTEXT
SystemVu Numeric point = SUB_MODE
SUBMTEXT
SUB_MODE
NO SUBMODE 0
NO SUBMODE 1
NO COOLING 2
ECON FREE COOLING 3
UNOCC. FREE COOL 4
MECH. COOLNG 5
ECON/MECH COOLING 6
DHUMI/MECH COOLING 7
DEHUMIDIFYING 8
DEHUM PREVENTED 9
COOLING PREVENTED 10
SHUTTING COOL OFF 11
NO HEATING 12
HEATING PREVENTED 14
SHUT TING HEAT OFF 15
OA TEMPERING 16
NO VENT 17
MODE TIMEGUARD 18
SUPPLY FAN ON 19
NO T EST 20
FACTORY ACCESS 21
MANUAL TEST 22
AUTO TEST 23
SHUTTING TEST OFF 24
MODE TIMEGUARD 25
IDLE --- NO D EMAND 26
UNIT DISABLED 27
URGENT SHUTDOWN 28
SAFETY CONTROL 29
STARTING UP 30
PURGING SMOKE 31
PRESSURIZING 32
EVACUATING SMOKE 33
SystemVu Display Name = VENT MODE
SystemVu Text poin t = VENTT E X T
SystemVu Numeric point = VENTSTAT
VENTTEXT
VENTSTAT
SUPPLY FAN OFF 0
CIRCULATION 1
P R E --- O C C P U R G E 2
IAQ OVERRIDE 3
MINIMUM POSITION 4
UNDER VENTILATION 5
OVER VENTILATION 6
DCV POSITION 7
FREECOOL POSITION 8
TESTING 9
SystemVu Display Name = DEMAND
SystemVu Text poin t = SYSDMDT
SystemVu Numeric point = SYS_DMD
SYSDMDT
SYS_DMD
NO DEMAND 0
FAN ONL Y 8
LOW COOL 17, 25
MED COOL 17, 25
HIGH COOL 19, 27
LOW COOL DEHUM 21, 29
MED COOL DEHUM 22, 30
HIGH COOL DE HUM 23, 31
LOW HEAT 33, 37, 41, 45
HIGH HEAT 35, 39, 43, 47
SERVICE TEST 49
FACTORY TEST 51
EMERGENCY 64
SMOKE PURGE 65
SMOKE PRESSURE 66
SMOKE EVAC 67
UFC LOW COOL 81
UFC MED COOL 82
UFC HIGH COOL 83
LOW UFC DEHUM 85
MED UFC DEHUM 86
HIGH UF C DEHUM 87
SHUTDOWN 96
SAFETY FAULT 112
