APPENDIX C: Navigatort Display
MODE -- RUN STATUS
ITEM EXPANSION RANGE UNIT WRITE STA TUS POINT
RUN STATUS
VIEW Auto View of Run Status
MODE Operating Mode see Appendix B MODETEXT
SUBM O p e r a t i n g S u b --- M o d e see Appendix B SUBMTEXT
S.DMD System Demand see Appendix B SYS_DMDT
LINK Linkage Active Yes/No YES LNK_ACT
OCC Currently Occupied Yes/No YES OCCUPIED
SAT Supply Air Temperature xxx..x °F SAT
COOL Cooling Status Menu
C.SPD Commanded IDF Speed xxx % FANSPEED
ACT.C Actual Cool Stage Active x ACTCSTGS
ODF.S Commanded ODF Speed xxxx rpm ODFSPD
EC.CP Econo Commanded Position xxx % YES DAMPCMD
OS.SP ODF Control SDT SP xxx.x °F ODFSDTSP
LA.ST Low Ambient Ctrl Status 0=Normal,
1=Entering,
2=Low Ambient,
3=Exiting
LACTRLST
RDHL Requested Dehum Level 0to2 REQDHLEV
MECH Mech Cooling Detail Menu
OK.MC Ok to use compressors? Yes/No OKMECHCL
MC.ON Mechanical Cool active? Yes/No MECHCOOL
MAX.C Max Allowed Cool Stages 0to3 YES MAXCSTGS
REQ.C Requested Cooling Stages 0to3 REQCSTGS
ACT.C Actual Cool Stage Active x ACTCSTGS
ODF.S Commanded ODF Speed xxxx rpm ODFSPD
TG.A1 Compressor A1 Timeguard xxx sec TIMGD_A1
TG.A2 Compressor A2 Timeguard xxx sec TIMGD_A2
TG.AL cmp Loader Timeguard xxx sec TIMG_ALD
SA.TR Supply Air Temp Trend xxx.x ^F/min SATTREND
ST.A1 Compressor A1 Strikes x A1STRIKE
ST.A2 Compressor A2 Strikes x A2STRIKE
HP.OV High Pressure Override Yes/No HP_OVR
C.LO Circuit A Locked Out Ye s/No CIRALOCK
LC.LO Low cooling locked out Yes/No LC_LOCK
MC.LO Medium Cooling lockout Ye s/No MC_LOCK
A1.AV Compressor A1 Available Yes/No CA1_AVAL
A1.L O Compressor A1 locked out Ye s/No CA1_LOCK
A2.AV Compressor A2 Available Yes/No CA2_AVAL
A2.L O Compressor A2 locked out Ye s/No CA2_LOCK
FC Free Cooling Detail Menu
OK.EC OKtoUseFreeCooling? Ye s/No OKFREECL
FC.ON Free Cooling active Ye s/No FREECOOL
FCSP Free Cooling SAT Setpnt xx.x °F FC_SATSP
REQ.D Requested Damper Pos xxx % REQDAMP
ECOK Econ Damper Operational Yes/No DAMPGOOD
E.LOC Dry Bulb Lockout Yes/No YES DBL OCK
EN.LO Enthalpy Lockout Yes/No YES ENTHLOCK
OK.UF Ok to unocc Free Cool? Yes/No OKTOUFC
UFC Unocc Free Cool Active Yes/No UFC_ACT
UF.LO Unocc Free Cool Lockout Yes/No UNOCLOCK
DHUM Dehumidification Menu
OK.DH OK to Dehumidify? Yes/No OKTODHUM
OK. FB OK to fan based dehum Ye s/No OKTOFBD
OK.HZ OK to use Humidimizer Ye s/No ODTOHUMZ
RDHS Req Compr DehumStgs 0to3 REQDSTGS
FL.SS FBDH SST locked out Yes/No FBDSSTLO
FL.SA FBDH SAT Lockout Yes/No FBDSATLO
HEAT Heating Status Menu
C.SPD Commanded IDF Speed xxx % FANSPEED
IFO IGC Fan On Request (IFO) On/Off IGC_IFO
REQ.H Requested Heating Stages 0to2 REQHSTGS
ACT.H Actual Heat Stage Active x ACTHSTGS
OK.HT OK to Run Heat Yes/No OKTOHEAT
MAX.H Max Allowed Heat Stages 0to2 YES MAXHSTGS
TG.H1 Heat Stage 1 Timeguard xxx sec TIMGD_H1
TG.H2 Heat Stage 2 Timeguard xxx sec TIMGD_H2
SA.TR Supply Air Temp Trend xxx.x ^F/min SATTREND
H.LOC All Heat Stages Lockout Yes/No YES ALLHTLOC
H1.AV Heat Stage 1 Available Yes/No HT1_AVAL
H2.AV Heat Stage 2 Available Yes/No HT2_AVAL
OK.ST OK to SupplyAirTempering Yes/No OKTOTEMP
