A11-2002 CIRCUIT MANUAL
8
INSTRUMENT PANEL (I/P) AND MFA
B=WHITE
N=BLACK
R=RED
M=BROWN
V=GREEN
A=BLUE
H=GREY
Z=PURPLE
G=YELLOW
F10 multi way converter J119 multi function display K6 engine self-check indicator
F15 voltage stabilizer K1 ABS warning indicator K7 oil pressure warning light
G20 fuel sensor K2 left turn indicator K8 engine overheat warning light
G25 coolant temperature sensor K3 right turn indicator
G30 RPM sensor K4 engine charging indicator K5 manual brake warning light
G35 preset fluid level compare meter K9/K10/K11/K12 instrument panel illumination light
J114 control unit K13 low beam headlight, position warning light
K14 high beam warning light Y1 digital clock
K15 fuel low warning light T1 single hole connector
