CIAT FLOWAY ACCESS User Manual

Step Action Result
15 Press the key Displays "AddrES"
16 Press the key
Displays the address, e.g. "1"
17 Press the key
Address hundreds digit ashes
18 Press the key
Scrolls through the values from 0 to 9, stop on the value "0"
19 Press the key
Hundreds = 0
Address tens digit ashes
20 Press the key
Scrolls through the values from 0 to 9, stop on the value "1"
21 Press the key
Hundreds = 0
Tens = 1
Address units digit ashes
22 Press the key
Scrolls through the values from 0 to 9, stop on the value "0"
23 Press the key
Hundreds = 0
Tens = 1
Unit = 0
24 Press and hold the key
Displays "AddrES"
25 Press the key
Displays "PArity"
26 Press the key
Displays the parity, e.g. "nonE"
27 Press the key
Parity text ashes
28 Press the key
Scrolls through the possible values "nonE", "Odd", "EuEn", stop on the text "nonE"
29 Press the key
Displays the parity "nonE"
30 Press and hold the key
Displays "PArity"
31 Press the key
Back to the "Prot" display
32 Press and hold the key
Displays "rS-485"
33 Press and hold the key
Displays "InStAnt"
34 Press and hold the key
Back to the main display of energy consumed value in KWh
If the energy meter is congured like this then connected via the RS-485 link, information circulation is
conrmed on the meter by the following icon:
.
5.2 - Associated parameters:
The parameter "P44 main box energy meter" present in the machine parameters is used to bring up the menu
"20.Energy meter" containing the meter reading parameters.
No. Description
Setting
Display conditions Access level
Enumeration By default
44 Energy meter
0: None
1: With
0 3
No. Description
Setting
Unit Display conditions Access level
Enumeration By default
3000 Energy consumed 0 kWh 1
3001 Instantaneous power 0 W 1
3002 Voltage 0 V Single-phase meter 1
3004 Voltage L1 - L2 0 V Three-phase meter 1
3005 Voltage L3 - L2 0 V Three-phase meter 1
3006 Voltage L1 - L3 V Three-phase meter 1
3008 Current L1 A Three-phase meter 1
3009 Current L2 A Three-phase meter 1
3010 Current L3 A 1
3012 Fault summary
0 : Fault not present
1 : Fault present
1
3013 Communication state
0 : ofine
1 : online
1
3014 Serial number 1
3015 Version number 1
5 - ENERGY METER CONNECTION AND ADDRESSING
FLOWAY ACCESS EN-34
