9.3 - Reading parameters
No. Description
Setting
Unit Display conditions
Access
level
Enumeration
Reading parameters
300 Calculated intake ow rate setpoint m
3
/h P104 Air intake ventilation control = Flow rate 1
301 Air intake fan ow rate m
3
/h 1
302 Air intake fan differential pressure Pa 1
304 Duct pressure calculated setpoint Pa P104 Air intake ventilation control = Duct pressure
305 Duct pressure Pa P104 Air intake ventilation control = Duct pressure 1
306 Calculated extraction ow rate setpoint m
3
/h 1
307 Air extraction fan ow rate m
3
/h 1
308 Extraction fan differential pressure Pa 1
320 Calculated cooling setpoint °C 1
321 Calculated heating setpoint °C 1
322 Supply air temperature °C 1
323 Fresh air temperature °C 1
324 Return air temperature °C 1
326 Room temperature °C P154 Target temperature selection = Room 1
331 CO
2
air quality ppm P152 Air quality control = With 1
338 Intake lter pressure switch 1
339 Exhaust lter pressure switch 1
340 Remote control 1
341 Setpoint 1 / Setpoint 2 P160 Setpoint 1/setpoint 2 = On/Off input 1
342 Fire P24 Fire detection = With 1
345 Mixed coil changeover thermostat
P28 Hydraulic coil no.1 = Mixed
and
P162 Changeover selection = On/Off input
1
350 DX unit control
P28 Coil = Cooling direct expansion or heating direct
expansion or reversible direct expansion
1
353 DX unit defrosting
P28 Coil = Cooling direct expansion or heating direct
expansion or reversible direct expansion
1
356 Electric heater safety thermostat P32 Elec. heater = 2 on/off stages 1
370 Isolation damper P26 Isolation damper = With 1
372 Air intake fan 1
373 Air intake fan operating-hour meter h 1
374 Air intake fan percentage % 1
376 Air extraction fan 1
377 Extraction fan operating-hour meter h 1
378 Extraction fan percentage %
380 AHU operating feedback 1
382 Calculated air quality requirement % P152 Air quality = With 1
392 Setpoint 1 / setpoint 2 status
P160 = Setpoint 1/setpoint 2 selection = Sched./CMS or On/
Off input
1
394 Calculated cooling demand % 1
395 Calculated heating demand % 1
398 Cooling block
0: off
1 : on
1
399 Heating block
0: off
1 : on
1
400 Coil 1 Cooling %
P28 Coil no.1 = cold water or mixed or cooling direct
expansion or reversible direct expansion
1
401 Coil 1 Heating %
P28 Coil no.1 = hot water or mixed or heating direct expansion
or reversible direct expansion
1
410 Stage 1 electric heater
0: off
1 : on
P32 Electric heater = 2 On/Off stages 1
411 Hour meter and stage 1 electrical heater h P32 Electric heater = 2 On/Off stages 1
414 Stage 2 electric heater
0: off
1 : on
P32 Electric heater = 2 On/Off stages 1
415 Stage 2 electric heater operating-hour meter P32 Electric heater = 2 On/Off stages 1
420 Bypass state
0 : inactive
1 : active
P32 Electric heater = 2 On/Off stages 1
422 Changeover state
0: heating
1: cooling
P28 Coil no.1 = mixed 1
440 DX unit run/shutdown
0: off
1 : on
P28 Coil = Cooling direct expansion or heating direct
expansion or reversible direct expansion
1
