CIAT FLOWAY ACCESS User Manual

9.7 - Input/Output directions
No. Description
Setting
Display conditions
Access
level
Enumeration By default
Adjust. params
850 Remote control input direction
0 : Normally open
1 : Normally closed
1 (NC) 2
851 Setpoint 1/Setpoint 2 input direction
0 : Normally open
1 : Normally closed
0 (NC) P160 Setpoint 1/setpoint 2 = On/Off input 2
852 Fire detection input direction
0 : Normally open
1 : Normally closed
1 (NC) P24 Fire detection = With 3
855 Changeover thermostat input direction
0: Open in heating
1: Closed in heating
1 (NC) P28 = mixed coil and P162 = On/Off input 3
856 Intake lter pressure switch input direction
0 : Normally open
1 : Normally closed
1 (NC) 3
857 Exhaust lter pressure switch input direction
0 : Normally open
1 : Normally closed
1 (NC) 3
866 DX unit defrosting input direction
0 : Normally open
1 : Normally closed
1 (NC)
P28 Coil = Cooling direct expansion or
heating direct expansion or reversible direct
expansion
2
867 DX unit control input direction
0 : Normally open
1 : Normally closed
1 (NC)
P28 Coil = Cooling direct expansion or
heating direct expansion or reversible direct
expansion
2
872 Electric heater manual safety input direction
0 : Normally open
1 : Normally closed
1 (NC) P32 Electric heater = 2 On/Off stages 3
882 Fault reporting output direction
0 : Normally open
1 : Normally closed
1 (NC) 2
885 AHU operating feedback output direction
0 : Normally open
1 : Normally closed
1 (NC) 2
886 DX unit control output direction
0: Open in heating
1: Closed in heating
1 (NC) P28 Coil = reversible direct expansion 2
9.8 - Motors
No. Description
Setting
Unit
Access
level
Enumeration By default
Air intake FMA settings
1200 Min. speed percentage 0 % 3
1201 Max. speed percentage 100 % 3
1202 Acceleration ramp-up 100 s 3
1203 Deceleration ramp-down 100 s 3
Air intake FMA 1 information
1220 Calculated min. speed rpm 1
1221 Calculated max. speed rpm 1
1222 Speed requested rpm 1
1223 Current speed rpm 1
1224 Current consumed A 1
1225 Power input W 1
1226 Motor temperature °C 1
1227 Operating counter h 1
1230 Fault summary
0 : inactive
1 : active
1
1231 Communication state
0 : inactive
1 : active
1
1234 Warning summary
0 : inactive
1 : active
1
1235 Warning status 1
1238 Motor type 1
1239 Version number 1
Extraction FMA 1 settings
2200 Min. speed percentage 0 % 1
2201 Max. speed percentage 100 % 1
2202 Acceleration ramp-up 100 s 1
2203 Deceleration ramp-down 100 s 1
9 - PARAMETERS
FLOWAY ACCESS EN-58
