CIAT FLOWAY ACCESS User Manual

9 - PARAMETERS
Below is the list of parameters which can be adjusted by the user (level 1 access - no password required), the installer (level 2
access), or the manufacturer (access level 3). The level 2 password can be requested from your technical support. Some parameters
are not always visible and depend on the machine's conguration.
9.1 - Machine parameters
No. Description
Setting
Display conditions
Access
level
Enumeration By default
1 Unit model 3
4
Characteristics of the pressure sensor for the
air intake fan
4 : 0-1600Pa 0,3-5V
5 : 0-1000Pa 0,5-4,5V
6 : 0-3000Pa 0,5-4,5V
5 (Depending on P01 Unit model) 3
5 Coefcient value K for the intake fan 4 Visible as read-only 3
12
Characteristics of the pressure sensor for the
air extraction fan
4 : 0-1600Pa 0,3-5V
5 : 0-1000Pa 0,5-4,5V
6 : 0-3000Pa 0,5-4,5V
5 (Depending on P01 Unit model) 3
13 Coefcient value K for the exhaust fan 4 Visible as read-only 3
24 Fire detection
0: None
1: With
0 3
26 Isolation damper
0: None
1: With
0 3
28 Hydraulic coil
0: None
1: Cold water
2: Cooling direct expansion
3: Hot water
4: Mixed (water)
5: Heating direct expansion
6: Reversible direct expansion
0 P32 = Without 3
32 Electric heater
0: None
2 : 2 stages
0 P28 = Without 3
44 Energy meter
0: None
1: With
0 3
51 Air intake FMA1 conguration
0: Not completed
1: Completed
0 3
71 Exhaust FMA conguration
0: Not completed
1: Completed
0 3
99 Conguration locked
0: unlocked
1: locked
0 3
9.2 - Settings parameters
No, Description
Setting
Unit Display conditions
Access
level
Enumeration By default
Adjust, params
100 Language
0: French
1: English
2: German
3: Spanish
4: Italian
5: Dutch
0 1
102 Date DD/MM/YYYY 1
103 Time HH/MM 1
104 Air intake ventilation control
1: Flow rate
2: Duct pressure
0 2
106
Multiplication factor value of the signal sent
by the air extraction fan with pressure control
in the supply air duct
1 P104 Air intake ventilation control = Duct pressure 2
108 Damper opening time delay 180 s P26 Isolation damper = With 2
110 AHU max ow rate P1 function m
3
/h Visible as read-only 3
111 AHU ow rate low limit threshold 50% P110 m
3
/h Visible as read-only 3
112 Air intake fan ow rate setpoint 1 10000 m
3
/h P104 Air intake ventilation control = Flow rate 1
113 Air intake fan ow rate setpoint 2 10000 m
3
/h
P104 Air intake ventilation control = Flow rate
and
P160 Setpoint 1/setpoint 2 selection = sched./
CMS, or On/Off input only or forcing
and
P161 Application of the setpoint 1/setpoint 2
selection = ventilation or temperature + ventilation
1
114
Air intake fan ow control PID proportional
band (P)
6000 m
3
/h P104 Air intake ventilation control = Flow rate 2
115
Air intake fan ow rate control PID integral
time (I)
20 s P104 Air intake ventilation control = Flow rate 2
9 - PARAMETERS
EN-51 FLOWAY ACCESS
