Cisco 2500 Series Installation And Configuration Guide

Table of Contents
Cable Specifications
Console and Auxiliary Port Signals and Pinouts
Identifying a Roll-Over Cable
Console Port Signals and Pinouts
Auxiliary Port Signals and Pinouts
Ethernet Cable Assembly and Pinouts
Token Ring Pinout
Synchronous Serial Cable Assemblies and Pinouts
EIA-530
EIA/TIA-232
EIA/TIA-449
V.35
X.21
Cable Specifications
This appendix provides the following pinout information:
Console and Auxiliary Port Signals and Pinouts●
Ethernet Cable Assembly and Pinouts●
Synchronous Serial Cable Assemblies and Pinouts●
Note All pins not listed in the tables in this appendix are not connected.
To order cables, see the section "Obtaining Service and Support" in the "Overview of the Router"
chapter.
Console and Auxiliary Port Signals and Pinouts
Your router comes with a console and auxiliary cable kit, which contains the cable and adapters you need
to connect a console terminal (an ASCII terminal or PC running terminal emulation software) or modem
to your access server. The console and auxiliary cable kit includes the following items:
RJ-45-to-RJ-45 roll-over cable. (See the next section, "Identifying a Roll-Over Cable," for more●
Cabling
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_fix/cis2500/2520/2520_23/c2520cab.htm (1 of 17) [10/27/2000 3:08:09 PM]
