Ejector Levers3SPA subslot 01
Status LED for SPA in subslot 14SPA subslot 12
The Cisco ASR 9000 SIP-700 LED is described in the following table.
Table 5: Cisco ASR 9000 SIP-700 LED
MeaningStateColorLED Label
SIP is powered and IOS-XR is loading.OnAmberStatus
SIP is active.OnGreen
SIP is not installed correctly or is not powered.OffN/A
Cisco ASR 9000 SIP-700 Physical Specifications
The Cisco ASR 9000 SIP-700 physical specifications are shown in the following table.
Table 6: Cisco ASR 9000 SIP-700 Physical Specifications
SpecificationsDescription
Occupies one line card slot on a Cisco ASR 9000 Series Aggregation Services RouterPhysical dimensions
10kg (22 lbs)Shipping weight
32 to 104°F (0 to 40°C)Operating temperature
10 to 90 percent, noncondensingRelative humidity
–4 to 149°F (–20 to 65°C)Storage temperature
SPA Subslot Numbering on the Cisco ASR 9000 SIP-700
The Cisco ASR 9000 SIP-700 supports up to 2 single-width, double-height SPAs, up to 4 single-width,
single-height SPAs, or up to 2 double-width, single-height SPAs. The Cisco ASR 9000 SIP-700 does not
support double-width, double-height SPAs.Note that while the OC192 POS SPA is single-width, single-height,
it is “logically” double-width in that it cannot run with another SPA in the adjacent bay, unless the other SPA
is shut down.
Bay 2 (Top Left)
Bay 0 (Top Right)
Bay 3 (Bottom Left)
Bay 1 (Bottom Right)
The following figure shows a Cisco ASR 9000 SIP-700 with 2 SPAs installed. The left SPA slot is subslot 0
and the right SPA slot is subslot 1.
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
5
Overview: Cisco ASR 9000 Series Router SPA Interface Processors
Cisco ASR 9000 SIP-700 Physical Specifications
