Cisco A9K-SIP-700 Hardware Installation Guide

Figure 10: LC Type Cable
1-Port OC-48 POS RPR SPA Overview
The following sections describe the 1-Port OC48-POS/RPR SPA:
1-Port OC48-POS/RPR SPA LEDs
The 1-Port OC48-POS/RPR SPA has eight LEDs, as shown in the following figure.
Figure 11: 1-Port OC48-POS/RPR SPA Faceplate
CARRIER LED5WRAP1
ACTIVE LED6PASSTHROUGH LED2
A/L (Active/Loopback)
LED
7MATESYNC LED3
STATUS LED8CAR (Carrier/Alarm)
LED
4
The WRAP, PASSTHRU, and MATESYNC LEDs apply to the SPA in RPR/SRP mode only.
Note
The 1-Port OC48-POS/RPR SPA LEDs are described in the following table.
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
17
Overview: Cisco ASR 9000 Series Router Shared Port Adapters
1-Port OC-48 POS RPR SPA Overview
